>> QT4-24 small production line block machines for house construction
>> QT4-24 small production line block machines for house construction manufacture capacity table
Size(L x W x H) | Pcs /Mould | Pcs / Hr | Pcs/day |
400x200x200mm | 4 | 554 | 4352-5540 |
400x240x200mm | 5 | 692 | 5536-6920 |
Besides above block sizes, it can produces other type blocks: hollow blocks, solid blocks, interlocking blocks etc.
>> QT4-24 small production line block machines for house construction specification
Main specification and technical parameters | |
Overall size | 2060(L)×1730(W)×2580(H)mm |
Shaping cycle | 24-30 seconds |
Pallet size | 850×550×40mm (bamboo) |
850×550×40mm (Plastic) | |
Vibration frequency | Max.4000 R/Min |
Upper vibrator | 2.2KW |
Nether vibrator | 6kw |
Electricity | 380V/220V/ (adjustable) |
Total weight | 3000 KGS |
>> QT4-24 small production line block machines for house construction main parts
1.Host machine
2.JD350 mixer
>> QT4-24 small production line block machines for house construction material
>> QT4-24 small production line block machines for house construction guarantee
(1)We can supply one year guarantee period for our brick making machines, if the client have the question ,they could call our service department number any time , we will supply per day 24 hours service .
(2)Within one year, if the client meet the unsolvable questions, we could fly to client place to help.
