Help CenterAutomatic Concrete Block Brick Making Machine QT4-26 Quality Choice
Related Products
-
Algerie QT4-26 Automatic Concrete Block Making Machine Best QualityUS$ 4,800 - 5,200MOQ: 1 Set -
QT4-26 Concrete Blocks Making Machine Mobile Hydraulic Semi Automatic MachineUS$ 4,800 - 5,200MOQ: 1 Set
-
Automatic QT4-26 Cheap Precast Concrete Hollow Block Making Machine for SaleUS$ 4,800 - 5,200MOQ: 1 Set
-
Algerie QT4-24 Automatic Concrete Block Making Machine Best QualityUS$ 4,800 - 5,200MOQ: 1 Set
-
Full Automatic Concrete Brick Making Machine/ Real Estate Construction Brick Machine/ PLC Control Block Making MachineUS$ 4,800 - 5,200MOQ: 1 Set
>> QT4-26 Manual Brick Making Machine |
>>The capacity of QT4-26 Manual Brick Making Machine |
No. | Block photo | Block size | Pcs/mould | Pcs/hour | Pcs/day |
1 | | 400x200x200mm | 4 | 450-500 | 2500-3500 |
2 |
| 400x150x200mm | 5 | 500-600 | 3500-4000 |
3 |
| 240x115x53mm | 24 | 3600 | 20000 |
>> QT4-26 Manual Brick Making Machine | ||
Overall size | 2060(L)×1730(W)×2580(H)mm | |
Shaping cycle | 24-30 seconds | |
Pallet size | 850×450×25mm (bamboo) | |
850×450×20mm (Plastic) | ||
Vibration frequency | Max.4000 R/Min | |
Upper vibrator | 2.2KW | |
Nether vibrator | 6kw | |
Electricity | 380V/220V/ (adjustable) | |
Total weight | 3000 KGS | |
Conveyor belt | ||
Belt width (M) | 6 | |
Belt length (M)/KW | 6/2.2 | |
Belt speed (M/S) | 2 | |
JD350 mixer | ||
Overall size | 1200(L)×1200(W)×1300(H)mm | |
Shaping cycle | 5 mins | |
Volume | 350L (25Kgs Cement) | |
Electricity | 380V/220V/ (adjustable) | |
Total weight | 330KGS | |
>> QT4-26 Manual Brick Making Machine main parts |
1.Host machine
2.JD350 mixer
>> QT4-26 Manual Brick Making Machine raw materials |
>> QT4-26 Manual Brick Making Machine guarantee |
(1)We can supply one year guarantee period for our brick making machines, if you have the question, you could call our service department number any time , we will supply per day 24 hours service . (2)Within one year, if the client meet the unsolvable questions, we could fly to client place to help. |
