Home > Instruments & Meters > Laboratory Instruments > Laboratory Thermostat > Popular Heating Circulator 50~300 Price

Popular Heating Circulator 50~300 Price

Name: Popular Heating Circulator 50~300 Price
Brand: TOPTION
SKU: 112016353
Availability: InStock

Popular Heating Circulator 50~300 Price thumbnail-1

Popular Heating Circulator 50~300 Price thumbnail-2

Popular Heating Circulator 50~300 Price photo-1

Popular Heating Circulator 50~300 Price photo-2

US$ 1,000 - 5,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Brand Name:

TOPTION

Model Number:

FL-800

Place of Origin:

Shaanxi, China

Contact Supplier Request Quote Chat Now

Xian Toption Instrument Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai/Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Brand Name TOPTION

Model Number FL-800

Place of Origin Shaanxi, China

Heating Circulator UC Series

UC series with function from high temperature to cooling process, from 300℃~50℃.

Description of heater:
1.UC series with function from high temperature to cooling process, from 300℃~50℃.
2.Equipped with heating cooling container, with large heat transfer area, fast heat-up and cool-down, small heat transfer oil demand.
3.Can heat-up and cool-down continuously.
4.The whole cycle is full closed,there is no oil mist at high temperature, heat transfer oil can not be oxidized and browning.
5.With function of internal PT100 for correcting internal circulation.
6.The whole system is closed with expansion tank, the expansion tank and liquid circulation are thermal insulation, do not participate in liquid circulation, regardless of high or low temperature, the medium in expansion tank is limited to 60℃.

Advantages of heater :

Small space required
Low filling Volume
High Pump Capacity
Rapid & efficient filling of the complete
application with venting
+60 °C max. expansion tank temperature
Simple operation
High level of safety through constant
monitoring

Technical Parameters of heater:

Model		UC-1820	UC-5020	UC-A020	UC-3030	UC-5030	UC-A030
Temperature range ℃		50℃~170℃	50℃~200℃	50℃~200℃	50℃~300℃	50℃~300℃	50℃~300℃
Controller		PID adaptive controller
Temp. Control optional		Heat-conducting medium outlet temp. control
Communication protocol		MODBUS RTU Protocol, RS 485 Interface
Temperature feedback		Heat-conducting medium temperature feedback PT100
Temp. accuracy		±0.5℃	±0.5℃	±0.5℃	±0.5℃	±0.5℃	±0.5℃
Heating power		2kW	5.5kW	10kW	3kW	5.5kW	10kW
Cooling capacity	300℃				3kW	5.5kW	10kW
	200℃	2kW at 170℃	5.5kW	10kW	2.5kW	5kW	9kW
	100℃	1.3kW	4kW	8kW	1.3kW	4kW	7kW
	65℃	0.6kW	1.8kW	3.4kW	0.6kW	1.8kW	3kW
		There is a heat exchanger in the system, it needs to cool by filling water, open the water valve automatically as request.
Circulation pump		Max10L/min 0.7BAR	Max35L/min 2BAR	Max50L/min 2BAR	Max15L/min 2BAR	Max35L/min 2BAR	Max50L/min 2BAR
Heater		Orient electric heater
Independent Temperature limiter		LNEYA
Cooler		KAORI Plate heat exchanger
Operation panel		Display setting temperature and testing temperature; Touch screen display
Safety protection		Self-diagnosis function; freezer overload protection; high pressure switch, overload relay, thermal protection device, liquid low level protection, high temperature protection and temperature fault protection.
Closed circulation system		The whole system is full closed circulation, there is no oil mist at high temperature and no water vapor at low temperature, pressure do not rise up when system is running. The system will supplement oil automatically at low temperature.
Connection size		DN15	DN20	DN-20	DN-20 PN-10 Connection flange
Dimension		320420500	500550800	500550800	500550800	6006001250	6006001250
Weight		35kg	78kg	88kg	85kg	95kg	105kg
Power		AC 220V 50HZ 2.2kW (max)	AC 380V 50HZ 5.9kW (max)	AC 380V 50HZ 10.8kW (max)	AC 380V 50HZ 3.2kW (max)	AC 380V 50HZ 5.9kW (max)	AC 380V 50HZ 10.8kW (max)
Case material		Cold rolled steel
Optional		Optional 7-inch color touch screen controller, temperature curve record, data export to excel format.
Optional		SUS304 case material
Optional power		220V 60HZ three-phase, 440V~480V 60HZ three-phase
