Ultra hd 4k2k 2160p 4-input 4-output Hdmi V1.4 Hdmi Matrix 4x4/ Remote Control via Rs232/us Plug

Ultra hd 4k2k 2160p 4-input 4-output Hdmi V1.4 Hdmi Matrix 4x4/ Remote Control via Rs232/us Plug photo-1
Ultra hd 4k2k 2160p 4-input 4-output Hdmi V1.4 Hdmi Matrix 4x4/ Remote Control via Rs232/us Plug photo-2
Ultra hd 4k2k 2160p 4-input 4-output Hdmi V1.4 Hdmi Matrix 4x4/ Remote Control via Rs232/us Plug photo-3
Negotiable MOQ: 50 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
CHEERLINK
Model Number:
HTM0404ANRS
Place of Origin:
Guangdong, China
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Brand Name CHEERLINK
Model Number HTM0404ANRS
Place of Origin Guangdong, China

ultra hd 4k2k  2160p  4-input 4-output hdmi v1.4 hdmi matrix 4x4/ remote control via rs232/US plug





What is the Features of our HDMI Switch 1.4 ?





CEC passby
 HDCP compliant
HDMI Stylish Switches with remote control
IR controlled  Switching or manual switching

Transfer bitrates up to 2.25 Gpbs per channel

Supports both AC-coupled and DC-coupled inputs

 Optimized Equalization for Enhanced Signal Integrity
Supports for 8-bit, 10-bit, and 12-bit deep color per channel
Sense the input source ports automatically ,and bypass the port without  signal

 ultra hd 4k2k 2160p 4-input 4-output hdmi v1.4 hdmi matrix 4x4/ remote control via rs232/us plugultra hd 4k2k 2160p 4-input 4-output hdmi v1.4 hdmi matrix 4x4/ remote control via rs232/us plug



What is the Specifications of our HDMI Switch 1.4?





Support resolution  2160P/1080P/1080i/720P/576P/480P/576i/480i
Support deep color up to 36bit
Support transfer bitrates up to 2.25Gpbs/per channel
Power supply DC5V
Input DDC Signal 5 volts p-p (TTL)
Input Tmds Signal 0.5-1.0 volts p-p
Operating humidity range 5 to 90 % RH (no condensation)
Operating temperature range -5 to +55℃(-41 to +95℉)
Support tmds clock frequency range 25~225Mhz
HDMI output cable distance ≤15m(if need longer, amplifier is needed )
Support audio format LPCM,Dolby-AC3,DTS7.1,DSD/Dolby TrueHD/ DTS-HD Master Audio
3DTV Support







Our HDMI SWITCH  application



  •  HDMI Switch input: DVD Player, HD-DVD Player, Blue Ray Player, Camcorder, SAT Receiver, Digital camera, PC, MAC Notebook, XBOX® 360 etc.
  •  HDMI Switch output: LCD TV, Plasma TV, TFT, Projector, HD-Ready or FULL HD TV etc.



ultra hd 4k2k 2160p 4-input 4-output hdmi v1.4 hdmi matrix 4x4/ remote control via rs232/us plug



Product photos



ultra hd 4k2k 2160p 4-input 4-output hdmi v1.4 hdmi matrix 4x4/ remote control via rs232/us plugultra hd 4k2k 2160p 4-input 4-output hdmi v1.4 hdmi matrix 4x4/ remote control via rs232/us plugultra hd 4k2k 2160p 4-input 4-output hdmi v1.4 hdmi matrix 4x4/ remote control via rs232/us plugultra hd 4k2k 2160p 4-input 4-output hdmi v1.4 hdmi matrix 4x4/ remote control via rs232/us plugultra hd 4k2k 2160p 4-input 4-output hdmi v1.4 hdmi matrix 4x4/ remote control via rs232/us plug

Packing list

1 x MatriX
1 x Adapter (US 2-oblate-pin plug, 143cm cable)
1 x Remote control (1 x CR2025 included)
1 x English user manual
1 x CD

ultra hd 4k2k 2160p 4-input 4-output hdmi v1.4 hdmi matrix 4x4/ remote control via rs232/us plugultra hd 4k2k 2160p 4-input 4-output hdmi v1.4 hdmi matrix 4x4/ remote control via rs232/us plug
