cheerlink hdmi v1.4 ultra hd 2160p 4k2k hdmi matrix 4x2 /remote control via rs232/black
With an increasing number of high-definition entertainment devices becoming available, such as games consoles, DVD players and set-top boxes, unless you happen to have the latest model of TV you are likely to find yourself severely lacking in HDMI ports with a large number of sets only possessing the one.
The solution to this problem is not buying a new High Definition Television with multiple HDMI Inputs, but instead, you invest in HDMI switches.
Cheerlink HDMI Switch is a premium quality High speed HDMI Switch for your gaming or home theater setup. It allows for switching up to 3 HDMI inputs into one output seamlessly and supports resolutions up to 4k.
Our HDMI switch has a remote control with an associated infrared receiver, so you can comfortably select the input source directly from your sofa. With this high quality HDMI switch, you can enjoy the very best audio and video quality.
What is the Features of our HDMI Switch 1.4 ?
| CEC passby |
| HDCP compliant |
| HDMI Stylish Switches with remote control |
| IR controlled Switching or manual switching |
Transfer bitrates up to 2.25 Gpbs per channel |
Supports both AC-coupled and DC-coupled inputs |
| Optimized Equalization for Enhanced Signal Integrity |
| Supports for 8-bit, 10-bit, and 12-bit deep color per channel |
| Sense the input source ports automatically ,and bypass the port without signal |
What is the Specifications of our HDMI Switch 1.4?
| Support resolution | 2160P/1080P/1080i/720P/576P/480P/576i/480i |
| Support deep color | up to 36bit |
| Support transfer bitrates | up to 2.25Gpbs/per channel |
| Power supply | DC5V |
| Input DDC Signal | 5 volts p-p (TTL) |
| Input Tmds Signal | 0.5-1.0 volts p-p |
| Operating humidity range | 5 to 90 % RH (no condensation) |
| Operating temperature range | -5 to +55℃(-41 to +95℉) |
| Support tmds clock frequency range | 25~225Mhz |
| HDMI output cable distance | ≤15m(if need longer, amplifier is needed ) |
| Support audio format | LPCM,Dolby-AC3,DTS7.1,DSD/Dolby TrueHD/ DTS-HD Master Audio |
| 3DTV | Support |
Our HDMI SWITCH application
- HDMI Switch input: DVD Player, HD-DVD Player, Blue Ray Player, Camcorder, SAT Receiver, Digital camera, PC, MAC Notebook, XBOX® 360 etc.
- HDMI Switch output: LCD TV, Plasma TV, TFT, Projector, HD-Ready or FULL HD TV etc.
Product photos
Packing list
1 x MatriX
1 x Adapter (EU 2-round-pin plug, 143cm cable)
1 x Remote control (1 x CR2025 included)
1 x English user manual
1 x CD
