Fully automatic WT2-10 soil brick making machine clay interlocking pavers
WT2-10 fully automatic clay brick making production line clay brick manufacturing machine
1. Big clay made into small size by soil crusher
2. Remove the big size clay, use small size clay only
3. Pour the clay and cement to mixer , mixing them with water
4. Transfer the finished raw material to host machine by conveyor machine.
5. Produce green block.
6. Carry the green block to curing aera.
WT2-10 fully automatic clay brick making production line clay brick manufacturing machine
WT2-10A hydraulic interlocking block machine | |
Overall size |
1400(L)×1100(W)×2100(H)mm |
Shaping cycle |
10-12 seconds |
Power |
7.5 KW |
|
12 Hp diesel engine |
Pressure |
16Mpa |
Total weight |
1300 KGS |
WT2-10 fully automatic clay brick making production line clay brick manufacturing machine
Overall size mm |
1100(L)×1100(W)×1400(H)mm |
Motor |
5.5KW |
Capacity |
500KGS/H |
Electricity |
380V/220V/ (adjustable) |
Total weight |
300 KGS |
WT2-10 fully automatic clay brick making production line clay brick manufacturing machine
Power |
3KW |
Capacity |
480KGS/h |
Rated power |
380V or 220V |
Size |
Diameter:500mm |
Total weight |
320 KGS |
WT2-10 fully automatic clay brick making production line clay brick manufacturing machine
Overall size mm |
1200(L)×1200(W)×1200(H)mm |
Mixing time |
3-5mins |
Feeding volume |
500L |
Output volume |
350L |
Power |
7.5 kw |
Total weight |
400 KGS |
Block size |
Piece/mold |
Pieces/hour |
Pcs/day |
300x150x100mm |
2 |
500-600 |
5000-6000 |
WT2-10 fully automatic clay brick making production line clay brick manufacturing machine
Block molds
Linyi Wante Machinery Co., Ltd established in 1994.our company has long engaged in the research,production and sales of building meterial and construction machine. There is state-of-the-art equipment, superb technology and high-standard test bases.Our company has always been adhering to the "integrity, pragmatism, innovation, development" spirit of enterprise, constantly absorbing
domestic and foreign advanced technologies and mature experience. After 10 years of unremitting efforts, we have rapidly developed into a leading enterprise in the industry.
Thanks for your attention, waiting to talk more with you.
