ZR-2050 Planktonic bacteria sampler /Environmental Equipment

Specifications

ZR-2050 Planktonic bacteria sampler /Environmental Equipment is high effective porous suction sampler.

               ZR-2050 Planktonic bacteria sampler /Environmental Equipment

Description of ZR-2050 Planktonic bacteria sampler /Environmental Equipment:

ZR-2050 air planktonic bacteria sampler is high effective porous suction sampler. Based on Anderson percussive principle, ZR-2050 with impact velocity 10.8 m/s, as the five grade of Anderson percussive grade. The getter device of equipment get air through porous sampling head, and impact to petri dish of ¢90m, then microorganisms in the air is captured by the agar medium. This equipment can be widely used in pharmacy, food, juice, running water industries, drug control institute, health and epidemic prevention, hospitals, etc.



Can meet the requests of GMP, ISO 14698-1/2, GB/T 16293-2010



Features and functions of ZR-2050 Planktonic bacteria sampler /Environmental Equipment:

1. Standard impact way, Screen type working mode, equal to five grade of Anderson percussive grade sophisticated air flow sensor. Constant current sampling, with high accuracy flow controlling. It will shut off automatically once insufficient battery power or flow mirror more than 2.5%.

2. Measure ambient temperature, atmospheric pressure automatically. Automatically maintain a constant current flow with the change of temperature, atmospheric pressure

3. AC-DC dual-use, with built-in high-energy lithium battery

4. Can be matched with professional A frame, the sampling height can be adjustable.

5. Large-capacity data storage

6. Dot-matrix liquid crystal display, Chinese and English operation.

7. User password protection

8. Fault detection automatic protection

9. There is no need to recalibrate the flow no matter under any temperature, sea level, atmospheric pressure.



Technical parameters of ZR-2050 Planktonic bacteria sampler /Environmental Equipment:

Main parameters	parameters	Resolution	Error
Sampling flow	100L/min	1L/min	≤±2.5%
Atmospheric pressure	(80~106)kPa	0.01kPa	≤±0.53kPa
Working temp	(-20~50)°C
Sampling volume range	(100~3000) L
Petri dish size	¢90mm
material	Anodized aluminum
Lithium battery	11.1V/4.4Ah
Charging power time	<6h
Battery working time	>10h
Power supply source	DC15V,3A
size	(diameter 150×235) mm
Noise	<60dB(A)
Weight	About 2kg
Power consumption	<20W
