FG-SPS2000/3000W Off-Grid Solar Power System

FG-SPS2000/3000W Off-Grid Solar Power System thumbnail-1
FG-SPS2000/3000W Off-Grid Solar Power System photo-1
US$ 300 - 1,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
KEMAPOWER
Model Number:
FG-SPS
Contact Supplier Request Quote Chat Now
Foshan Kemapower Electronics Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Guangzhou
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name KEMAPOWER
Model Number FG-SPS
Specification Normal
Application Commercial
Output Voltage (V) 220V/110V
Load Power (W) 2KW-3KW
Solar Power (W) 2KW-3KW
Work Time (h) 6-8 hours

Off-Grid Solar Power system

Key feature

Off-Grid Solar Power system FG-SPS2000/3000W
* Grid hybrid design optional
* Output: 2KW or 3KW, N-PSW Sine Wave Inverter
* generated energy(KWH/D): 5.2 for 300W, 6.4 for 600W
* System DC voltage: 24VDC
* Bat.: Gel, 18*100AH for 2KW, 22*100AH for 3KW
* Controller: 2*MPPT30A for 2KW, 2*MPPT40A for 3KW
* Solar Panel: 10*MO150 for 2KW, 12*MO150 for 3KW
* PV mountion: 5 array for 2KW, 6 array for 2KW
* Bat. Cabinet: With wheels, A20 for 2KW, C24 for 3KW. Inverter and controller on the top or mount on wall



TECHNOLOGY SPECS



Battery based OFF-GRID solar system,
used for home or office
MPPT charge controller to increase
   charge current more than 30%  compared
   to conventional
High efficiency inverter to reduce    the
   static power wastage
Battery type selector and adjustable
   charge voltage to precise battery
   requirements
PWM charge control and three step
   charge to prolong battery life
extensible capacity design for   future
   requirement
Grid hybrid solar Inverter is   optional



ITEM MODEL FG-SPS2000W FG-SPS3000W
 System power  Rated power  capacity(watts) 2000W 3000W
 capacity
 System rated DC   24VDC 24VDC
 voltage
 System output  Voltage 220V50HZ or 110V/60HZ 220V50HZ or 110V/60HZ
 Phase Single phase Single phase
 Wave form Pure sine wave Pure sine wave
  effectual recharge time mini 6 hours. Longer time will Generate more electricity capacity
 Generate electricity   5200WH/day 6400WH/Day
 capacity
 Reference loads and  only for Reference. You can use the other loads also.please connect with  Kemapower to get more advice for different loadsc ondition
 expend  TV 25 inch 1PCS 6 horus 2PCS 6 horus
   Desk Fan 4PCS 5 horus 4PCS 5 horus
   Ceiling Fan 1PCS 5 horus 1PCS 5 horus
   Energy Save Lamp 6PCS 4 horus 6PCS 4 horus
   Energy Save Lamp 2PCS 4 horus 2PCS 4 horus
   Computer 1PCS 4 horus 1PCS 4 horus
   Home Printer 1PCS 0.5 horus 1PCS 0.5 horus
   Home Water Pump 1PCS 2 horus 1PCS 2 horus
   Washing Machine 6KG 1PCS 0.7 horus 1PCS 0.7 horus
   Refrigerator 160L 1PCS 24 horus 1PCS 24 horus
   micro-wave oven / 1PCS 0.5 horus
   Expend capacity 5200WH/day 6400WH/Day
 Power Inverter  Mode N-PSW2KW/24VDC N-PSW3KW/24VDC
   Max load capacity 2000W 3000W
 Design features High Frequency Pure sine wave
 Protection short circuit, overload,battery low,
 Efficiency > 88%
 Standing by wastage less than 12W less than 12W
 Remark please to the N-PSW series product details
 Grid hybrid Inverter  (optional)  Mode N-PSW2K-G N-PSW3K-G
 Combine Charge voltage 24VDC 24VDC
 Combine Charge current 0-40Amp for requirement 50Amp for requirement
 Charger manage CPU control three step charge stage
Transfer voltage transfer to Grid power when DC < 21.0V or 42V. Back to Battery mode again when DC
> 37.4V or 74.8V
 Controller Mode/PCS MPPT1224-30,2PCS MPPT1224-40AMP,2PCS
Rated charge current 60AMP 80AMP
Rated charge voltage 24VDC 24VDC
Charge control mode Series PWM charge mode & State of Charge(SOC),Automatic compensation
 Remark               please refer to the MPPT series product details
 Battery Bank  Mode 100AH/12VDC GEL 100AH/12VDC GEL
 Battery type Deep cycle gel battery
 Capacity 900AH/24VDC, 18P 2200AH/12VDC,22P
 Battery cabinet A20. 4 layer with wheels C24. 4layer
 backup days 3 days under for the Reference loads and expend. Extensible
 Remark please refer to the GEL series product details.
 Solar module  Mode MONO150WP/35VDC MONO150/35V
 capacity 150WP*10PCS 150WP*12pcs
 Cell efficiency 14.13% 14.13%
 Solar mounting 5 array for 10*150WP 6 array for 12*150WP
 The other parts  Breaker,Arrester,wire collector,Cables set
