PV Module GYP 3-85W

Name: PV Module GYP 3-85W
Brand: KEMAPOWER
SKU: 112010199
Availability: InStock

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

KEMAPOWER

Model Number:

GYP 3-85W 12V 24VDC

Foshan Kemapower Electronics Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen/Guangzhou

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name KEMAPOWER

Model Number GYP 3-85W 12V 24VDC

Material Polycrystalline Silicon

PO SERIES TECHNOLOGY SPECS

Temperature Coefficients of Isc(%)°C	0.04	Allowable Hail Load	23m/s ,7.53g
Temperature Coefficients of Voc(%)°C	-0.38	Junction Box Type	Pass the TUV Certificate
Temperature Coefficients of Pm(%)°C	0.047	Bypass Diode Rating(A)	12
Temperature Coefficients of Im(%)°C	0.04	Caple & Connector Type	Pass the TUV Certificate
Temperature Coefficients of Vm(%)°C	-0.38	Backing (Brand Type)	TPT
Temperature Range	-40eC to +85eC	Warranty	90% of 10 years,80% of 25 years.
Tolerance Wattage(e.g.+/-5%)	±5%	Standard Test Conditions	AM1.5 1000W/ 25 +/-2°C
Surface Maximum Load Capacity	2400Pa	FF (%)	70-76%

Model	Max power	Cell Size	Cell Array	Cell Efficiency	Max	Max	Short	Open	Dimension	Weight
	(W)	(mm)		(academic)	Power	Power	Circuit	Circuit	(mm)	(Kg)
	(W)	(mm)		(academic)	Current (A)IMP	VOltage ( V) VMP	Current(A)ISC	Voltage(V)VOC
GYP3-18	3	78x22.285	2X9	10.63%	0.32	9	0.48	10.9	155X225X17	0.8
GYP5-18	3	78x26	2X9	10.64%	0.54	9	0.62	11.3	300X185X17	0.8
GYP5-36	5	78X15.6	2X18	11.72%	0.29	17.1	0.33	21.5	355X185X25	0.8
GYP10-36	10	78X26	4X9	14.10%	0.58	17.2	0.65	21.6	360X305X25	1.2
GYP20-36	20	78X52	4X9	14.20%	1.16	17.2	1.29	21.6	555X355X25	2.5
GYP25-36	25	78X78	4X9	11.72%	1.45	17.2	1.61	21.6	555X355X25	2.9
GYP30-36	30	78X78	4X9	14.10%	1.74	17.2	1.94	21.6	763X345X25	3.2
GYP35-36	35	78X78	4X9	16.40%	1.94	18	2.04	22.2	763X345X25	3.2
GYP35-36A	35	156X52	4X9	12.40%	2.06	17	2.31	21.4	670X535X35	4.5
GYP37-36	35	156X52	4X9	12.40%	2.04	16.8	2.3	21.3	670X535X35	4.5
GYP40-36	40	156X52	4X9	14.10%	2.32	17.2	2.58	21.6	670X535X35	4.5
GYP45-36	45	156X52	4X9	15.80%	2.48	18.2	2.65	22	670X535X35	4.5
GYP50-36	50	156X78	4X9	11.80%	2.98	16.8	3.32	21.2	771X676X35	6.2
GYP60-36	60	156X78	4X9	14.10%	3.48	17.2	3.87	21.6	860X670X35	6.2
GYP65-36	65	156X78	4X9	15.20%	3.63	17.9	3.89	21.9	771X676X35	6.2
GYP70-36	70	156X78	4X9	16.30%	3.89	18	4.09	22.2	810X670X35	6.2
GYP70-36A	70	156X104	4X9	12.40%	4.12	17	4.63	21.4	1080X670X35	8.5
GYP75-36	75	156X104	4X9	13.20%	4.39	17.1	5.05	21.5	1080X670X35	8.5
GYP80-36	80	156X104	4X9	14.10%	4.65	17.2	5.17	21.6	1080X670X35	8.5
GYP85-36	85	156X104	4X9	14.90%	4.77	17.8	5.25	21.9	1080X670X35	8.5
ATTENTION	OEM/ODM is welcome
ATTENTION	the specs are subject to change without notice at anytime
