WT Series mobile cone crusher
Stone crusher, Aggregate Crusher, Rock crusher, Jaw Crusher, Impact Crusher, Cone Crusher, Hammer Crusher, Roll Crusher, Crushing Line, Crushing equipment spare parts
Mobile crusher plant provides a new field of business opportunities for contractors, quarry operators, recycling and mining applications. It offers high efficient and low cost project plan without environment limit for the client.
Mobile crusher plant details:
This series of mobile crusher plant incorporates all the equipments together on one truck, which has high chassis, narrower body compared with other trucks, this ensure the crushing plant be easily transported on highways and moved to crushing sites, so it is able to achieve on-site crushing without material transporting from one place to another place. In addition, the lengthened plant is able to transport the final products to the motor-lorry directly. it can start to work soon even in the bumpy ground without reinstallation, so it saves more time and money than fixed crushing plant which needs to install individual equipment one by one.
Mobile crusher plant compatibility:
Mobile crusher plants can work independently or together with other devices according to coarse crusher or fine crusher requirements. Side discharging chute supports more screening and transporting ways. Diesel generators of the incorporated plant can not only supply power for this plant, but also supply power for other plants of the process flow.
WT Series mobile cone crusher
cone crusher of this series is suitable for crushing various mid-hard and above mid-hard ores and rocks .This crusher has the advantage of reliable construction , high productivty, easy adjustment and less cost in operation . The spring release system of crusher acts as an overload protection system that allows foreign iron pieces to pass through the crushing chamber without damages to the crusher . It uses the two kinds of sealed forms : dry oil and water to make rock powder if made plaster stone and engine oil separated , assuring reliable performance . The type of crushing chamber depends upon the size of feed and fineness of the crushed product . The standard type is applied to medium crushing , the medium type is applied to medium or fine crushing and the shorthead type is applied to fine crushing .
Specification |
Dia of cone at big end (mm) |
Width of feed opening(mm) |
Adjusted scope of output(mm) |
Yield (t/h) |
Speed of eccentric shaft (r/min) |
Motor (kw) |
Pressure of spring(kn) |
Dimention LWH (mm) |
Weight (t) |
||
PYB900 |
900 |
135 |
15-50 |
50-90 |
330 |
55 |
700 |
3050×1640×2350 |
10.18 |
|
|
PYZ900 |
900 |
70 |
5-20 |
20-65 |
330 |
55 |
700 |
3050×1640×2350 |
10.19 |
|
|
PYD900 |
900 |
50 |
3-13 |
15-50 |
330 |
55 |
700 |
3050×1640×2350 |
10.27 |
|
|
PYB1200 |
1200 |
170 |
20-50 |
110-200 |
300 |
110 |
1500 |
4150×2300×2980 |
24.7 |
|
|
PYZ1200 |
1200 |
115 |
8-26 |
50-150 |
300 |
110 |
1500 |
4150×2300×2980 |
25 |
|
|
PYD1200 |
1200 |
60
|
3-15 |
18-105 |
300 |
110 |
1500 |
4150×2300×2980 |
25.6 |
|
|
WT Series mobile cone crusher
Mobile Jaw crusher Photos:
