QT10-15 fully automatic salt block making machine
Main advantages:
1>> QT10-15 fully automatic hollow block making machine With the use of advanced electronic control technology and reliable hydraulic system
2>> QT10-15 fully automatic hollow block making machine
Use special synthesis of double-ended output vibration technology to optimize the vibrator vibration
3>> QT10-15 fully automatic hollow block making machine With table and mould vibration together making the concrete in 2 seconds to fully liquefied exhaust and
ensure that high-density.
4>> QT10-15 fully automatic hollow block making machine
Advanced vibration technology and arch-breaking devices are both used
1. Full line for hollow block
1. cement silo (extra).(build in local place or buy from us)
2. PLD1200 batching machine
3. JS750 mixer
4. QT10-15 block machine
5. colorful materials system
6. block sweeper
7. stacker machine
2. Paver making need parts
1.colorful material system
2.colorful material mixer
nveyor belt
3. QT10-15 fully automatic salt block making machine specification :
Main specification and technical parameters | |
Overall size |
3500x2220x2850mm |
Shaping cycle |
15-20 seconds |
Pallet size |
1350x780x30mm (bamboo) |
1300x900x30mm (plastic) | |
Vibration frequency |
Max.4000 R/Min |
Electricity |
380V/220V/ (adjustable) |
Vibration force |
120KN |
Total weight |
13000 KGS |
4. QT10-15 fully automatic salt block making machine Capacity table
No. |
Block size |
Pcs/mould |
Pcs/hour |
Pcs/day |
1 |
400x200x200mm |
10 |
2100 |
21000 |
2 |
400x150x200mm |
11 |
2310 |
23100 |
3 |
400x100x200mm |
12 |
2520 |
25200 |
5. One machine with one set free mould, the pattern and design as followed:
