concrete blocks QT4-15C block making machine,product algeria
Advantages :
1>> QT4-15C brick making machine, its pressure system become two hydro-cylinders
2>> QT4-15C brick making machine uses the Siemens motor (or ABB) which is with best quality. Its life is 1.3 times than common motor
3>> QT4-15C brick making machine Japan Mitsubishi PLC control system.
4>> QT4-15C brick making machine can be controlled through the menu.
QT4-15C fully production line including:
PLD800 batching machine, JS500 mixer, QT4-15C host machine
PLD800 batching machine specification
Model |
PLD800 |
| Weigh bucket capacity (L) | 800 |
| Productivity (m3/h) | 48 |
| Batching precision | ±1% |
| Max weighing capacity (kg) | 3000 |
| Number of material matching | 2 |
| Work loading height (mm) | 3000 |
| Feeding belt speed (m/s) | 1 |
| Power (kw) | 12 |
| Gross weight (kg) | 3000 |
Demission (mm) |
5800*2200*3500 |
JS500 mixer specification
Model |
JS500 |
|
Charging Capacity (L) |
800 |
|
Discharging Capacity (L) |
500 |
|
Production Capacity (m3/h) |
≥25 |
|
Max Aggregate Diameter (mm) |
≤40/60 |
|
Cycle Time (s) |
72 |
|
Stirring Vane |
Rev Speed (r/min) |
31 |
Quantity |
2×7 |
|
|
Stirring Motor |
Model | |
| Power (KW) | 18.5 | |
| Lifting Motor | Model | |
| Power (KW) | 5.5 | |
|
Pump Motor |
Model | |
| Power (KW) | 0.75 | |
|
Dimensions ( mm) |
Travel State | 3030×2520×2880 |
| Operation State | 5025×3100×5680 | |
concrete blocks QT4-15C block making machine,product algeria specification
Main specification and technical parameters | |
Overall size |
3500x2100x2550mm |
Shaping cycle |
15-18 seconds |
Pallet size |
1010x550x25mm (bamboo) |
1010x550x25mm (plastic) | |
Vibration frequency |
Max.4500 R/Min |
Electricity |
380V/220V/ (adjustable) |
Vibration force |
55KN |
Total weight |
5000 KGS |
concrete blocks QT4-15C block making machine,product algeria Capacity table
No. |
Block size |
Pcs/mould |
Pcs/hour |
Pcs/day |
1 |
400x200x200mm |
4 |
960 |
7680 |
2 |
400x150x200mm |
5 |
1200 |
9600 |
3 |
400x100x200mm |
6 |
1440 |
11520 |
5. Raw material
6. Bricks
