WANTE MACHINERY QT10-15 russia compressed earth brick block machine
- 1600 Set / Sets per Month
- Qingdao
- T/T Credit Card
Product Details
Place of Origin: | Shandong, China | Brand Name: | Wante Brand | Model Number: | QT10-15 |
After-sales Service Provided: | Engineers available to service machinery overseas |
Packaging Details
China standard package, usually in container
Product Description
WANTE MACHINERY QT10-15 russia compressed earth brick block machine
Main advantages:
1>> With the use of advanced electronic control technology and reliable hydraulic system.
2>> Use special synthesis of double-ended output vibration technology to optimize the vibrator vibration.
3>> With table and mould vibration together making the concrete in 2seconds to fully liquefied exhaust
and ensure that high-density.
4>> Advanced vibration technology and arch-breaking devices are both used.
1. Full line for hollow block making machine
1. cement silo (extra).(build in local place or buy from us)
2. PLD1200 batching machine
3. JS750 mixer
4. QT10-15 block machine
5. colorful materials system
6. block sweeper
7. stacker machine
2. Paver making need parts
1.colorful material system
2.colorful material mixer
nveyor belt
3. WANTE MACHINERY QT10-15 russia compressed earth brick block machine specification:
Main specification and technical parameters | |
Overall size | 3500x2220x2850mm |
Shaping cycle | 15-20 seconds |
Pallet size | 1350x780x30mm (bamboo) |
1300x900x30mm (plastic) | |
Vibration frequency | Max.4000 R/Min |
Electricity | 380V/220V/ (adjustable) |
Vibration force | 120KN |
Total weight | 13000 KGS |
4. WANTE MACHINERY QT10-15 russia compressed earth brick block machine Capacity table:
No. | Block size | Pcs/mould | Pcs/hour | Pcs/day |
1 | 400x200x200mm | 10 | 2100 | 21000 |
2 | 400x150x200mm | 11 | 2310 | 23100 |
3 | 400x100x200mm | 12 | 2520 | 25200 |
5. WANTE MACHINERY QT10-15 russia compressed earth brick block machine photos
Wheel loader
PLD1200 Batcing machine
JS750 MIXER
SCREW SACLE
6. WANTE MACHINERY QT10-15 russia compressed earth brick block machine
Paver molds
7. WANTE MACHINERY QT10-15 russia compressed earth brick block machine
quality control
Thanks for your attention,if you have interested in our machines,please contact me :
HAVE A GOOD DAY !
Company Profile
Linyi Wante Machinery Co., Ltd. has long engaged in the research, production and sales of block making machines. There is state-of-the-art equipment, superb technology and high-standard test bases. Our company has always been adhering to the "integrity, pragmatism, innovation, development" spirit of enterprise, constantly absorbing domestic and foreign advanced technologies and mature experience. After 10 years of unremitting efforts, we have rapidly developed into a leading enterprise in the industry.
Our main products: aerated concrete production lines, concrete block making machines, hydraulic paver block machines, cement pipe machines, widely used in building materials, roads and bridges, energy and others. On the foundation of the domestic market, we focus on the development of international market. Our products have been exported to more than 100 countries and regions, such as Africa, Southeast Asia, the Middle East and South America, with frequent international business dealings. We have established a good market reputation.
Our company has a perfect quality management system, and has passed the ISO9001:2000 international quality management system certification. Besides, our company has established our own sales network in many countries around the world, and has set up sales branches and service outlets in major cities across the country. So we are able to provide our clients with timely and convenient service.
We adhere to the brand philosophy that "excellence, do first-class products, creating a model for the industry", and enhance the brand ideology of "building the brand quality, service, innovation, positive enterprising, noble professionalism" to drive our company forward to a first-class enterprise.
