QT6-15 Hydraulic Press Cement Block Machinery infromation
QT6-15 Hydraulic Press Cement Block Machinery allocation
1> Host machine
2> Conveyor belt machine
3> Mixer
4> Mould
5> Stacker
6>Other fittings
QT6-15 Hydraulic Press Cement Block Machinery introduction
Forming machine main theoretical data | |||
Dimension of host machine |
2850×2200×2850mm |
control style |
PLC |
forming style |
Hydraulic |
Vibration force |
80KN |
vibrator style |
table and mould vibrate together |
raw material feeding style |
360 degree revole |
forming hight |
40-250mm |
moulding period |
15-20S |
moulding aera |
800×600mm |
size of pallet |
940×830×25mm |
weight of host machine |
11.5T |
Mixer style |
JS500 |
General water Consumption |
8T/day |
Voltage |
220/240/380/440V |
Simple block machine line area needed | |||
Workshop |
200m2 |
||
Office |
100m2 |
||
Total area |
About 2000m2 |
||
Worker arrangement | |||
operate |
1 |
Material loader |
1 |
Drive forklift |
1 |
Feeding pallets |
1 |
Maintain |
1 |
Total |
5 |
Production capacity | |||
Size(L x W x H) |
Pcs /Mould |
Pcs / Hr |
Pcs/day |
400X100X200 |
12 |
2160-2880 |
21600-28800 |
400X150X200 |
8 |
1440-1920 |
14400-19200 |
400X200X200 |
6 |
1080-1440 |
10800-14400 |
400X250X200 |
4 |
720-960 |
7200-9600 |
QT6-15 Hydraulic Press Cement Block Machinery paver block need parts
1. Colorful material feeding system
2. Colorful material mixer
3. Conveyor belt
Machinery for building blocks QT6-15 guarantee
(1)We can supply one year guarantee period for our brick making machines, if the client have the question ,they could call our service department number any time , we will supply per day 24 hours service .
(2)Within one year, if the client meet the unsolvable questions, we could fly to client place to help.
