Non-armored Steel Wire Strength Aerial Fiber Optic Cable (GYXTY)
Introduction:
The fibers,125μm,are positioned in a loose tube made of a high modulus plastic.The tubes are filled with a waterresistant filling compound... Two parallel steel wires are placed at the two sides of the steel tape.The cable is completed with a polyethylene (PE) sheath.
Main Technical Parameters:
Fiber Parameters:
No. |
Items |
unit |
Specification |
|
G652D | ||||
1 |
Core Diameter |
μm |
9/125 |
|
2 |
Cladding Diameter |
μm |
124.8±1.0 |
|
3 |
Core Non-Circularity |
% |
≤5.0 |
|
4 |
Cladding Non-Circularity |
% |
≤1.0 |
|
5 |
Core-Cladding Concentricity Error |
μm |
≤1.0 |
|
6 |
Coating Diameter |
μm |
245±7 |
|
7 |
Coating Non-Circularity |
% |
≤6.0 |
|
8 |
Cladding-Coating Concentricity Error |
μm |
≤12.0 |
|
Cable Parameters:
Items |
Specifications |
|
Fiber Count |
2-24 |
|
Colored Coating Fiber |
Dimension |
250µm±15µm |
Color |
Blue,Orange,Green,Brown,Gray,White,Red,Black,Yellow,Purple, Pink,Aqua |
|
Loose Tube |
Dimension |
2.5mm±0.05mm |
Material |
PBT |
|
Color |
Natural |
|
Strength Member |
Diameter |
1.0mm |
Material |
Steel Wire |
|
Outer Jacket |
Dimension |
8.0mm±0.3mm |
Material |
HDPE |
|
Color |
Black |
|
Mechanical and Environmental Characteristics:
Items |
Unite |
Specifications |
Tension(Long Term) |
N |
1000 |
Tension(Short Term) |
N |
2000 |
Crush(Long Term) |
N/10cm |
1000 |
Crush(Short Term) |
N/10cm |
3000 |
Min. Bend Radius(Dynamic) |
mm |
20D |
Min. Bend Radius(Static) |
mm |
10D |
Installation Temperature |
℃ |
-20~+60 |
Operating Temperature |
℃ |
-40~+70 |
Storage Temperature |
℃ |
-40~+70 |
Pictures:
If you have any interest about our products,please be free to contact with me anytime.
Contact with me:
Skype:mickeyma90
Phone:+8618758357139
