Low price factory-use ozone generator water filter water purifier with cooling system

air source water cooling and air cooling Ozone generator

In water treatment, the solubility of ozone scope is 0.1mg / L ~ 10mg / L. The lower concentration could be for water disinfection and purification. And a high concentration could be as "ozone water disinfectant"Ozone water disinfection and sterilization is rapid and occur in an instant. To kill the bacteria in 0.5-1.0 minute;

Under the concentration of 4PPM (mg / L) to kill hepatitis B virus 100% in 1.0 minute.

Herbold reports: Under 20 °C conditions, the ozone concentration in water 0.43mg / L, can be 100% kill of E. coli,and under the 10 °C to kill all E. Coli at 0.36Mg/L only;

The ozone concentration 0.25-0.38Mg/L, kill all HAV in the several minute.

Product formation:

Ozone generator unit (10 g/h), Ozone power supply (discharge ignition coil), Air compressor, Stainless steel shell, Voltmeter, Cooling fan, Ozone adjusting knob and Indicator lights.

Feature :

Stainless steel housing,smart titanium off quartz tube structure of ozone generator, the design of long life, high concentrations of ozone, its power and volume is smaller than similar products.

Product function:

1. Microcomputer control system, realizes the unmanned management.

2, Automatic startup shutdown, can set up multiple times.

3, Insurance automatic fuse circuit malfunction. Use air cooling, air source.

4. Cooling method: water cooling+ air cooling.

5. Can realize continuous working for a long time.

Parameter:

Model Number:Sw-015-10g

ozone output:10g/h,

net weight:20KG

Dimension of equipment:450*300*500mm

Equipment utilization:220v /50-60HZ,

Power Consumption:200w

Ozone medium:Smart titanium off quartz tube

Ozone gas source:air source

Cooling way:water cooling and air cooling

The outlet concentration: 20-30 mg/l

The sterilization efficiency: 99%

Certification: CE , ISO9001
