Special Offer 300w Vertical Axis Wind Turbine
Our strength lies in
1.The development and manufacture of lightweight,small-to medium-sized wind generators that generate up to 2kw power of power.our lightest wind turbine is only 13,5kg
2. Wind turbine blade diameter of 1.4m which is made by resin transfer molding(RTM).
3.Wind generators IP65-rated and can be assembled in five minutes.
4.Many of our wind turbines have earn patents in mainland China,
5. All of our wind power generator come CE, RoHS, and SGS-marked.
6.Our wind generator lead times are short-for standard orders we only need seven days.
Contact us now.
Technical parameter of wind generator:
| Model | FD1.5-0.3 | ||
| Rated power | 300W | ||
| Generator style | 3-phase AC PM | ||
| Generator rated voltage | AC 36/18 | ||
| Rotor diameter | 1.5m | ||
| Rated wind speed | 11m/s | ||
| Start-up wind speed | 2m/s | ||
| Working wind speed | 3~20m/s | ||
| Survival wind speed | 35m/s | ||
| Rated rotate speed | 840r/min | ||
| Inverter rated AC output | AC 220 | ||
| Blades material and quantity | fiberglass-reinforced plastics*3 | ||
| Heavy wind protection | Dump wind protection+Electromagnetic brake | ||
| Speed regulation method | mechanical yawing+Electromagnetic Brake | ||
| Shell material | alloy aluminum | ||
| Off-grid controller | 300W 12V/24V | ||
| Off-grid Inverter | 300W single phase | ||
| Free-standing tower height | 6m | ||
| Suggested battery capacity | 12V 100AH 2PCS | ||
Product Show
Effsun promise:
Pre-sales
1. Free consultation of renewable energy technology, products and solutions.
2. Free high reliability solutions for local conditions.
3. Exact and suitable configuration, with supplier positioning
4. Ensure reliability, insist on "saving every penny for customer "
In-sales
1. Comply with contract, provide proactive service.
2. Quality first, delivery on time.
3. Free consultation of installation, using, and maintenance technology.
After-sales
1. Establish a complete, traceable product quality record.
2. Regular and active return visit.
3. Reply complaint in 2 hours, provide solution in 24 hours.
