Wind Turbine Manufacturers
Wind turbine Products Advantages:
A, All of our products conform to CE and ISO9001 quality standards.
B, Small& light structure&Low start-up wind speed.
C, 40% more electricity generated,Swift start at low wind speed.
D, Less investment and quick recovery.
E, NIce value and quality,25 years lifespan.
F, Reliable in more working conditions
G, rated power at low wind speed
H, 3-Phase Permanent Magnet AC Generator, direct driven, no gearbox, and not need windward.
Apllication:
Light,fan, charger,TV,pump, washer,refrigerator,electric cooker,air conditioner,village power supply
Instruction:
Our wind turbine products are an electromechanical device used to convert wind energy into mechanical energy and then into electric energy. The electric power output from aero-generator can be used to charge storage batteries for energy storage and the stored electric energy and be transformed into the 110/120/220/230/240V/50Hz/60Hz alternating power supply or the power supply of local voltage and frequency.
Technical parameters of wind turbine :
Technical parameter | |||
Model |
FD3.2-1 |
Rated power (W) |
1000 |
Maximum output |
1510 |
Rated voltage (V) |
220 |
Rotor diameter (m) |
3.2 |
Start-up wind speed (m/s) |
2.5 |
Working wind speed (m/s) |
3~20 |
Working temperature |
from -30to +65 |
Rated RPM (r/m) |
500 |
Blade material |
fiber glass |
Shell material |
arroy |
Generator style |
3-phase AC PMG |
Blade quantity(pcs) |
3 |
Annual generation min/max(KWH) |
1500-3000 |
Matched inverter type |
Sine wave |
Suggested battery capacity |
12v150AH4PCS |
Certificate |
CE,RoHS,ISO9001:2000 |
||
Please contact us by phone or check on our website.() Thanks !!!
Mian parts
Relevent parts(generator)
1000W Controller
Installation diagram
We Wish Make Everyone Enjoy Clean Energy!
