YIMEI belt type filter press is a new-style high-efficiency sludge treatment equipment developed by our company based on the digestion and absorption advanced foreign technology , which has the advantages of high efficiency, low energy consumption, better dehydration effect, simple structure, easy maintenance, low noise, steady operation, safe and reliable, continuous automatic production etc. now have widely used in solid-liquid separation, such as the project of petroleum, chemical, coal, metallurgy, building materials, light textile, food and water supply and drain environmental protection etc.
Sludge belt filter press increased concentration based on original belt filter press , sludge concentration including condensed section, dehydration section, sludge mixed reaction system, which can put the second pond sludge (water ratio 99.2-99.6%) concentrated dehydration directly, thus eliminating the traditional enrichment pool, saving a lot of investment. Belt filter is an efficiency equipment by further dehydrating process of concentrated (water ratio 95-98%) material into filter cake dehydration ,with the feature of continuous automatic production, low production cost and installation, can change different mesh filters, continuous stepless speed regulation, adapting to different kinds of material solid-liquid separation.
item |
YMYL1000 |
YMYL1500 |
YMYL2000 |
filtering belt width(mm) |
1000mm |
1500mm |
2000mm |
main driven power(kw) |
1.1kw |
1.5kw |
2.2kw |
system total power(kw) |
13.47kw |
16.72kw |
18.92kw |
cleaning water pressure(Mpa) |
<0.5Mpa |
<0.5Mpa |
<0.5Mpa |
cleaning water volume(m3/h) |
8~10m3/h |
12~15m3/h |
15~18m3/h |
main machine operation weight(kg) |
3100kg |
4300kg |
5500kg |
(m) |
5.0x2.0x2.0m |
5.26x2.45x2.38m |
5.26x2.98x2.38m |
(%) feed moisture content |
95~97 |
||
|
(%) Mud cake moisture |
65~82 |
||
treatment capacity(m3/h) |
3~ |
6~10 |
10~15 |
[Q]How to buy your idea products?
[A]You can provide us your water sources, water quality, flow rate and ground area (contact us for more details).
[Q]What is your payment terms?
[A]TT and L/C are acceptable and TT will be more appreciated.30% deposit in advance and balance before loading.
[Q]What is the delivery time?
[A] It depends on order quantities. Generally speaking, the delivery time will be within 4 to 6 weeks.
[Q]How to pack the products?
[A]We use standard package. If you have special package requirements, we will pack as required, but the fees will be paid by customers.
[Q]How to keep your equipments from corrosion?
[A]We use the world-famous paint, like SigmaCoatings,PainBow,etc. What's more, we paint strictly according to the standard process.
[Q]How do you manufacture your equipment ?
[A]Our machining technology includes laser/plasma cutting, automatic welding,CNC cutting and bending.
[Q] How to install after the equipments arriving destination?
[A] We will provide detailed illustrations to you. If it is necessary, we will send technicians to help you.
