Specifications
1.SIP Protocol2.IMEI change
3.BTS change and lock
4.SIM rotation
ACOM516 series is able to process traditional voice call service and internet data service. Compare to the ACOM508 GSM/CDMA/WCDMA series VoIP Gateway,ACOM516 series adapt new hardware and software structure, which supports up to 16 concurrent calls.
Specification:
Model |
ACOM 516-16/64 |
Number of Channels |
16 channels |
Frequency |
GSM: 850/900/1800/1900MHz |
CDMA:450/800/1900MHz | |
WCDMA:850/900/1800/1900/2100MHz | |
SIP Specification |
SIP/2.0 RFC3261 |
Session Timer RFC4028 | |
STUN | |
Network Protocols |
DHCP/PPPoE/VPN(pptp) |
NTP | |
Telnet/HTTP/FTP/TFTP | |
Encryption:Ejoin,VOS2000,RC4,XOP.Base64 | |
Telephony Features |
Hot-line call ,Dial plan, Speed dial, Phone book, CDR, LCR, White/Black list |
Telephony Signaling |
DTMF tone dectection/generation |
DTMF relay: in-band, RFC 2833 and SIP info | |
Call forward: unconditional, no answer and busy | |
N-way conferencing | |
Caller ID display/generation, Mobile Number Portability | |
Voice Capability |
Voice codecs:G729a/b/e,G723.1,G.711 A/U law, iLBC |
Echo cancellation | |
Silence suppression & detection(VAD, CNG) | |
Adaptive jitter buffer | |
Volume adjustable | |
IVR customized | |
Number of Ports |
1 WAN 10/100Base-T ethernet(RJ-45 connector) |
1 LAN 10/100Base-T ethernet(RJ-45 connector) | |
1 Console(USB) | |
LEDs |
1 Power and 16 groups of card online and running status indicator |
Power Supply |
100-240VAC, 50 - 60 Hz IN, 12V/5A OUT |
Operating Environment |
Operating temperature: 0 - 50ºC |
Operating humidity: 10 – 90%RH | |
Warranty |
12 Months |
Mobile Features:
l SMS Send, Receive and Forward(GSM/SIP/HTTP)
l SMS Inbox
l AT Command , USSD
l SMS Format: PDU/TXT
l PIN Code Management
l CDMA Delay Answer
l GSM Polarity Reversal
l Carrier Selection
l Caller ID Hidden(need SIM Card support)
Maintenance and Management:
l Multi-language Interface
l USB Serial COM
l Configuration Backup and Restore
l Support HTTP/TFTP Upgrade
l Call statistics: ASR,ACD,PDD
l Ejoin Remote Management System
Special Features:
l Support G729a/b/e,G723.1,G.711 A/U law, iLBC auto-selecting
l EBO(Ejoin Bandwidth Optimization)
l Proxy Encryption Solution for IP Block
l Support SIM Bank
l VPN(pptp)
l SIM Card Rotating(ACOM516-64)
u Solution to solve the SIM card blocked by:
² Accumulated Call Duration
² Accumulated Connected Calls
² Accumulated Calls
² Consecutive Failed Calls
² Consecutive No-Alert Calls
² Consecutive No-Answer Calls
² Consecutive No Carrier Calls
² Consecutive Short-Duration Calls
l Station intelligent switching
l ERMS(Ejoin Remote Management System)
l Port Inter-Calling
l Fake Ringback
l Call Duration Limitation for SIM Card/Single
l Dial Plan/Prefix Inward Translation/Intelligent Routing
l Web Browser: Firefox/Chrome /IE/Opera
1.Uplink and Downlink
2.Solution
Accesories:
Technical support:
7×24 Hours Stand By !!!
Contact Way:
Name: Cherry Chang
skype:ejointech-h
QQ Chat:1414209628
Viber/whatsapp: +86 18476572872
Shenzhen Ejoin Technology Co.,Ltd. (Ejointech )was founded in Shenzhen, China in 2003, focused on VoIP technologies and solutions. With our expertise in high quality analog/digital voice gateways, media trunks, IP phones, Video phones, IPPBX, IVR, ACD and value added applications, we also provides specialized service as powerful and flexible based-SIP VoIP communication solutions, OEM and ODM services for carriers and providers around the world.
