Intermediate Wire Drawing Line Machine for Aluminium Wire Making

Intermediate Wire Drawing Line Machine for Aluminium Wire Making thumbnail-1
Intermediate Wire Drawing Line Machine for Aluminium Wire Making thumbnail-2
Intermediate Wire Drawing Line Machine for Aluminium Wire Making thumbnail-3
Intermediate Wire Drawing Line Machine for Aluminium Wire Making thumbnail-4
Intermediate Wire Drawing Line Machine for Aluminium Wire Making thumbnail-5
Intermediate Wire Drawing Line Machine for Aluminium Wire Making thumbnail-6
Intermediate Wire Drawing Line Machine for Aluminium Wire Making photo-1
Intermediate Wire Drawing Line Machine for Aluminium Wire Making photo-2
Intermediate Wire Drawing Line Machine for Aluminium Wire Making photo-3
Intermediate Wire Drawing Line Machine for Aluminium Wire Making photo-4
Intermediate Wire Drawing Line Machine for Aluminium Wire Making photo-5
Intermediate Wire Drawing Line Machine for Aluminium Wire Making photo-6
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
HONTA
Model Number:
HT-250-17DT
Contact Supplier Request Quote Chat Now
Kunshan City Hongtai Machinery & Electric Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Jiangsu, China
Brand Name HONTA
Model Number HT-250-17DT
Usage Drawing

Specifications

Intermediate wire drawing machine with annealer and double take up for drawing aluminium wires.







Product Description





Description of HT-250-17DT Intermediate wire drawing machine:




Inlet diameter                                                : Max.Φ 3.5 mm
Outlet diameter                                             :  Φ0.4-Φ 1.6mm
Drawing speed                                              : max 1800m/min
Drawing passes                                             : max 17
Exterior diameter of dies                                : Φ25mm &.Φ32mm
Area reduction                                               :  the final die is 18.6%, others are 25%
Diameter of drawing capstan                        :  Max. Φ250mm
Diameter of finished capstan                        :  Φ 250mm
Power of drawing main motor                       : AC55 kw
installed power                                              : 330 kVA
normal electricity consumption                      : approx. 360 kWh
cooling water consumption                            : approx. 25 m3 /hr
Compressed air                                              :12 -18 m3 /hr
Bobbin for spooler                                          : DIN 630 ( Drawing will be provided by customers)
Operation direction                                         : left to right or right to left (to be confirmed by customers)
Noise level                                                       :< 85 dbA (Except for main motor )
Line dimension (L X W X H)                           : approx.11000×4600×4500









Intermediate wire drawing line machine for aluminium wire making
