Medium Copper Wire Drawing Machine With Annealer
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
HONTA
Model Number:
HT-250-17DT
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Jiangsu, China
Brand Name
HONTA
Model Number
HT-250-17DT
Usage
Drawing
Composition of HT-250-17A/HT-2000A/HT-630A intermediate drawing machine with annealer:
(1).HT-250-17A drawing machine 1 set
(2) HT-2000 annealing machine 1 set
(3) HT-180 tension controller 1 set
(4) HT-630A spooler 1 set
(5) Electrical control system 1 set
Technical parameters:
Inlet wire diameter: max. 3.5mm
Outlet wire scope: φ0.4mm-φ1.6mm
Machinery speed: max. 1800m/min
Quantity of dies: max 17
Dimension of dies: φ25X12mm
Area reduction: the last die is18.6%, others are 25%
Diameter of drawing capstans: max φ250
Power of drawing main motor: DC75kw & AC55 kw
Dimension of drawing machine (L×W×H): 1215×550×3400
Net weight of drawing machine: approx.3200 kgs
