Intermediate Wire Making Machine

Intermediate Wire Making Machine thumbnail-1
Intermediate Wire Making Machine photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
HONTA
Model Number:
HT-250-17D
Contact Supplier Request Quote Chat Now
Kunshan City Hongtai Machinery & Electric Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Jiangsu, China
Brand Name HONTA
Model Number HT-250-17D
Usage Multifunctional

Features of the Machine:

Fully submersible drawing lubricant
Tungsten carbide drawing cone,Capstan

High accuracy gear driven, Short oil protection



Main technical specification:

1. drawing machine

Max inlet diameter Φ3.5mm

Outlet diameter range Φ0.4mm-Φ1.6mm

Max machanical speed 1800m/min

Max number of dies 17 pieces

Oval diameter of die 25mm

Max drawing cone diameter Φ250mm

Capstan diameter Φ250mm

Main motor power DC75 or AC55 driven by inverter

Machine dimensions 2400*1250*1400mm

Machine weight Approx. 3500kgs



2. Online annealer:

Rated DC Annealing Current 2000A

Maximum DC Annealing Voltage 60 V

Annealing Capacity 170KVA

Protection by steam

Weight About 1800 kgs

Drive by the flat belt from the finished capstan

Compressed Air:

Working pressure 0.6 ~ 0.7Mpa

Fluctuating value ±0.02Mpa

Dew point -25°C

Flow rate 50L/min

Water quality:

Pressure 0.2~0.4Mpa

Temperature ≤25°C

Hardness of Water for Steam Generator Max 5 dH

Hardness of Water for Annealer Max 12 dH



3. Spooler:

Max rotate Speed 1800 r/min

Max. movable distance of the shaft 150 mm

Max. travel distance of bobbin lifter 150mm

Spooling motor 11kW;1500r/min

Traverse motor servomotor 1KW 3000r/min

Bobbins DIN 630

Brake hydraulic type, emergency stop within 5 seconds;

Bobbin loading and unloading by hydraulic liftor;

Wire traverse speed automatically detect the changes of the speed
