Help CenterHT-15DT Fine Wire Drawing Machine With Annealer Wire Equipment Manufacturer
Related Products
-
Fine Wire Drawing Machine and Double Spooler With Continuous AnnealerNegotiableMOQ: 1 Set -
Fine Wire Drawing Equipment High Speed Electric Cable Making EquipementNegotiableMOQ: 1 Set
-
Fine Wire Drawing MachineNegotiableMOQ: 1 Set
-
HT-24DT High Speed Fine Wire Drawing Machine With AnnealerNegotiableMOQ: 1 Set
-
High Speed Fine Wire Drawing MachineNegotiableMOQ: 1 Set
Specifications
Fine wire drawing machine:1.Inlet dia: 1.6
2.Outlet dia: 0.20-0.68
3.Speed: 1500mpm
4.With online annealer
PART ONE Description of HT-15DT Fine wire drawing machine with annealer:
1. Applicable raw materials: hypoxia or oxygen free red copper wires, Max. Inlet is 1.6mm.
2. Control method: wire drawing, and spooling controlled and transmitted by AC motor, annealing controlled by DC motor, PLC+ human-machine controlling.
PART TWO Main technical data:
Inlet diameter: Φ1.6mm
Outlet diameter: Φ0.20-Φ0.68mm
Drawing line speed: 1500mpm/max
Main motor power: 18.5KW
Take-up motor power: 4KW
Annealer method: DC three-section annealing
Suitable diameter of spool: Φ300mm
Revise system: PID synchronous control spooler
Capacity for wire receiving: 50kg
Using voltage: 380
Brake way: Magnetic brake
Machine dimention: 2568L*1538W*2974H
Machine weight: 3000kgs
PART THREE Certificate:
PART FOUR Main market:
PART FIVE Packing:
