Main data:
(1) Wire inlet range: Ø0.5--Ø0.6mm
(2) Wire outlet range: Ø0.05--Ø0.18mm
(3) Machinery speed: 2000MPM/Max
(4) MAX. Use number of dies: 20 dies (provide by buyer)
Min. use number of dies: 13 dies (provide by buyer)
(5) Outline size of dies: Ø25mm×8~12mm
(6) Machinery reduction rate: the first to the 19th is 11.5%
The 20th is 6.5%
(7) Main motor: 10HP-4P AC motor and 10HP inverter
(8) Spooler motor: 5HP-4P AC motor and 5HP inverter
(9) bobbin loading capacity: 20KG
(10) Bobble outer dia. Ø280mm/ Max request a big internal diameter in order to next send-out program
(11) Braking: Plate brake
(12) Electric consumption: 7~11KW
(13) Exterior size of machine: 1900L×1350W×1750Hmm
(14) Machinery weight: net weight1800kg, total weight 1900kg.
