Fine Wire Drawing Machine With Annealer
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
HONTA
Model Number:
HT-14DT
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Jiangsu, China
Brand Name
HONTA
Model Number
HT-14DT
Usage
Drawing
Part one Description of HT-14DT Fine wire drawing machine with annealer:
HT-14DT annealing machine is to use short-circuit contact annealing principle, annealing power is DC, applied to the annealing soft production of copper line, annealing machine makes up of the conductive system, oxidative protection systems, cooling systems, drying systems, electrical systems and other components. The way of oxidative production steam adopts steam protection (the device comes with a steam generator); cooling lubrication using the dilute concentration of drawing cycle. Generally speaking , it needs setting up pools or an external heat exchanger to cool (external heat exchangers and cooling towers by the user-owned); drying system uses compressed air and mold to dry. The used cooling water and compressed should be prepared by the user. The SCR of annealing electrical control adopts strong fan to cool.
Part two Main technical data:
| Outlet diameter | Φ0.8-Φ1.6mm |
| Inlet diameter | Φ0.25-Φ0.6mm |
| Drawing line speed | 1200mpm/max |
| Main motor power | 15KW |
| Annealing power | 30KW |
| Take-up motor power | 5.5KW |
| Annealer method | DC three-section annealing |
| Suitable diameter of spool | Φ300mm |
| Revise system | PID synchronous control spooler |
| Capacity for wire receiving | 50kg |
| Using voltage | 380 |
| Brake way | Magnetic brake |
| Machine dimention | 2568L*1538W*2974H |
| Machine weight | About 3000kgs |
