Home > Manufacturing & Processing Machinery > Feeder > Vibrating Feeder > CMC VG VIBRATING GRIZZLY FEEDERS
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Application:
Feeding and scalping
Power Type:
Electric
Payment & Shipping
Payment Methods:
Port of Shipment:
KEELUNG/TAIWAN
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
CMVG Grizzly Vibrating FeedersNegotiableMOQ: 1 Set -
CMC V SERIES VSI VERTICAL SHAFT IMPACT CRUSHERNegotiableMOQ: 1 Set
-
CMC V Series Vertical Impact Crusher Horizontal Shaft Impact CrusherNegotiableMOQ: 1 Set
-
Impact Crusher/CMC V Series Vertical Impact CrusherNegotiableMOQ: 1 Set
-
CMC IMPACT CRUSHERNegotiableMOQ: 1 Set
Condition
New
Application
Feeding and scalping
Power Type
Electric
Capacity(t/h)
350~1300
Place of Origin
Taiwan, China
Brand Name
CMC
Model Number
Refer to list below
Power(W)
25-100VS
Certification
CMC
Warranty
one year
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
Designed for constant load feeding and scalping of blasted stone.Easily adjustable feed capacity.
vibrating grizzly feeder
VG Grizzly Vibrating Feeders
Taiwan Patents: 142131/140589
Product Describe:
VG Grizzly Vibrating Feeder is designed to be special applied ib blasted stone crushing process. It is usually primary crusher, with both feeding and scalping functions. Unique intergrated casting alloy grizzly bars have advantages of no clog, endurable life time and easy replacement. Extraordinary long through length to ensure smooth feeding. Flexible power transfer by universal joint can minimize bearing load&waer.
Advantage:
♦ Casting alloy grizzly with high rigidity can be free from clogging
♦ Service life of grizzly bars is extended 3 ~ 5 times compared to convention design due to extreme anti-avrasion property.
♦ Long through length to ensure smooth feeding
♦ Variable speed motor is equipped to easily adjusted feeding rate
♦Flexiable universal joint power transfer to minimize bearing loading.
Specifications:
Model | VG945 | VG1365 | VG1665 | VG1965 | VG2265 |
Max Feed Size(mm) | 550*400*300 | 740*480*370 | 960*640*480 | 1160*770*650 | 1360*905*680 |
Grizzy Length | 840 | 840 | 840 | 840 | 840 |
Vibration Freq | 600-950 | 600-950 | 600-950 | 600-950 | 600-950 |
Motor Power | 25V.S | 40V.S | 60V.S | 75V.S | 100V.S |
Capacity | 350-500 | 450-750 | 550-950 | 650-1150 | 800-1300 |
Dimensions(mm) | 920*4500 | 1260*6500 | 1600*6500 | 1940*6500 | 2280*6500 |
