HYM-600W 12v DC to AC 110v/230v modified sine wave car power inverter with USB port DC 5V 500MA
Products Features :
·Small size , light weight and potable
·Easy to use and high efficiency
·Green LED indicates power on,Red LED indicates wrong
·Input & output isolation
·Muti-protection function
·USB output port: 5V 500mA
· Built-in Cooling Fan
Protection Features:
·Low voltage protection
·Over voltage protection
·Overload protection
·Over temperature protection
·Short circuit protection
·Reverse connect protection
Power inverter specifications
Max continuous power |
600W |
Peak Load Power Rate |
1200W |
Wave form |
Modified sine wave |
NO load current draw |
<0.4A |
Input DC voltage Range |
10V-15V OR 21-30V |
Output Voltage Range |
230V +/- 10% or 110V +/- 10% |
Output Frequency Range |
50+/-3HZ OR 60+/-3HZ |
USB OUTPUT |
DC 5V 500MA |
Max Outer Temperature |
< 65°C |
Max Power Efficiency |
> 90% |
High Voltage Cut Off Level |
15-16V OR 30-32V |
Low Voltage Alarm Level |
10.6V+/-0.6V OR 21.2V+/-1.2V |
Low Voltage Cut Off Level |
10V+/-0.5V OR 20V+/-1.2V |
Overload and Short-circuit Protection: |
YES |
Input Voltage |
DC 12V OR DC 24V |
Built-in Cooling Fan: |
YES |
Q 1. what's the payment terms?
Q 2. how's the delivery time ?
A. usually it will take about two weeks for production
Q 3. tell me the standard of package?
A. For the small capacity, it use carton, but for big capacity, we should use strong wooden case for protection.
Q 4. what kind of material of transformer?
A. For servo type stabilizer,we have two types, one 100% copper and the other is copper with aluminum.It depends on your r
Q 5.Could you offer Form A or C/O ?
A. It totally not a problem. We can prepare relative documents to forgin affairs office or other office to apply for
Q 6.Would you accept to use our logo ?
A.If you have good quantity,it absolute no problem to do OEM.
Q 7.We want to know month capacity.
A. It depends on which model.For example for relay type small capacity , month capacity can reach near 10000pcs and big capacity near 2000pcs.
Q 8.Where is your market?
A. Our products are popular inNorth America, South America, Eastern Europe, Southeast Asia, Africa, Oceania,
Q 9. what kind of certificate you have ?
A. Our company already achieve ISO9001, and for products, we have CE,PCT,SGS.
