HYM-300W dc to ac Modified Sine Wave OR Pure Sine Wave Cheap Car Power Inverter With Bettery Charger

HYM-300W dc to ac Modified Sine Wave OR Pure Sine Wave Cheap Car Power Inverter With Bettery Charger thumbnail-1
HYM-300W dc to ac Modified Sine Wave OR Pure Sine Wave Cheap Car Power Inverter With Bettery Charger photo-1
US$ 10 - 20 MOQ: 50 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
GECHY
Model Number:
HYM-300 Power Iverter
Contact Supplier Request Quote Chat Now
Yueqing Gechy Import And Export Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo/Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name GECHY
Model Number HYM-300 Power Iverter
Output Power 201 - 300W
Output Type Single
Size 185x105x60
Weight 0.85kg
Input Voltage 12V OR 24V DC
Output Voltage 115V+/-10% OR 230V+/-10%
Type DC/AC Inverters
Output Frequency 50Hz/60Hz
Output Current <0.3A

HYM-300W dc to ac Modified Sine Wave OR Pure Sine Wave cheap car power inverter with bettery charger

  HYM-300W dc  to ac Modified Sine Wave OR Pure Sine Wave cheap car power inverter with bettery charger

Product Description



Function & Characteristic

1.Input Voltage Range of 12V DC or 24V DC

2.Output Voltage Range of 115V AC or 230V AC

3.For use in cars,boats,trucks,trailers and mobile homes.

4.Take the power inverter to camping and get AC power for lamps,radios or TVs.

5.In an emergency such as blackout,attach the power inverter to your car battery or portable battery and get power to run your appliances.

6.Ultra-Compact Metal Housing

Small and rugged;stored easily in any tool box,briefcase or glove compartment.

7.Low-Battery Alarm/Shutdown

Automatically detects low voltage and shuts down to protect your battery.

8.Integrated Fuse Protection

Protects your battery and power inverter from damage due to outlet overload.



Power inverter specifications

Model

HYM-300

Output power(Continuous Watts)

300W

Output power(Peak Watts)

600W

No load Current Draw

<0.3A

Nominal Input Voltage(DC)

12V(10~15V)  OR  24V(20~30V)

Nominal Output Voltage(AC)

115V+/-10%  OR  230V+/-10%

Frequency

50+/-2HZ  OR  60+/-2HZ

Output Waveform

Modified Sine Wave OR Pure Sine Wave

High Battery-voltage Shutdown(Volts)

15.5+/-0.5V  OR  30+/-1V DC

Low Battery-voltage Alarm(Volts)

10.5+/-0.5V  OR  21+/-1V DC

Low Battery-voltage Shutdown(Volts)

10+/-0.5V  OR  20+/-1V DC

Efficiency

80~85%

Thermal Protection

65°C+/-5°C

Overload



≥360W

Shut down&Alarm,restart when load is under rated power

Battery Polarity Reverse

By fuse replacement

Output Short-circuit

Output short-circuit protection,do not damage the circuit

With Cooling Fan

Auto-operation fan(load)

Product Dimension(L*W*H)MM



185x105x60



Weight(KG)

0.85

 HYM-300W dc to ac Modified Sine Wave OR Pure Sine Wave cheap car power inverter with bettery charger

HYM-300W dc to ac Modified Sine Wave OR Pure Sine Wave cheap car power inverter with bettery chargerHYM-300W dc to ac Modified Sine Wave OR Pure Sine Wave cheap car power inverter with bettery chargerHYM-300W dc to ac Modified Sine Wave OR Pure Sine Wave cheap car power inverter with bettery charger

FAQ



Q 1. what's the payment terms?

A. We accept LC, T/T, PayPal, Western Union, Small-amount payment, Money Gram
Q 2. how's the delivery time ?
A. usually it will take about two weeks for production
Q 3. tell me the standard of package?
A. For the small capacity, it use carton, but for big capacity, we should use strong wooden case for protection.
Q 4. what kind of material of transformer?
A. For servo type stabilizer,we have two types, one 100% copper and the other is copper with aluminum.It depends on your r
equirment. In fact,those two have no difference if normal work well. Only except the longlife. Copper is better
 and also higer price.For relay type stabilizer,we use toroid coils, the material is aluminum. comparing with square coils,toriod coils with high efficiency.
Q 5.Could you offer Form A or C/O ?
A. It totally not a problem. We can prepare relative documents to forgin affairs office or other office to apply for
 this certificate.
Q 6.Would you accept to use our logo ?
A.If you have good quantity,it absolute no problem to do OEM.
Q 7.We want to know month capacity.
A. It depends on which model.For example for relay type small capacity , month capacity can reach near 10000pcs   and big capacity near 2000pcs.
Q 8.Where is your market?
A. Our products are popular inNorth America, South America, Eastern Europe, Southeast Asia, Africa, Oceania,
 Mid East, Eastern Asia, Western Europeand so on.Some of them are our regular customers and some of them
 are developing. We hope you can join us and make mutural benifit from our cooperation.
Q 9. what kind of certificate you have ?
A. Our company already achieve ISO9001, and for products, we have CE,PCT,SGS.
HYM-300W dc to ac Modified Sine Wave OR Pure Sine Wave cheap car power inverter with bettery chargerHYM-300W dc to ac Modified Sine Wave OR Pure Sine Wave cheap car power inverter with bettery charger
