Home > Products > New Products > Z3050X10 Radial Drilling Machine
Z3050X10 Radial Drilling Machine
USD $9,000 - $12,000
/ Set
1 Set(Min.Order)
- 50 Set / Sets per Month
- qingdao
- T/T
You May Like
-
Vertical Facing And Centering Machine VZ820550
-
CNC Cylindrical Grinding Machine MA2060/MP2060
-
Inner Race Milling Machine QYXB125
-
grey color interlocking kelly bar, drill pipe for Bauer Sany Soilmec XCMG Casagrande
-
Friction kelly bar,yellow color kelly bar for rotary Bauer Sany Soilmec XCMG Casagrande
-
new design friction kelly bar, Rotary drill pipe for Bauer Sany Soilmec XCMG Casagrande
Product Details
| Condition: | New | CNC or Not: | Normal | Place of Origin: | Shandong, China |
| Brand Name: | GOOD | Model Number: | Z3050 |
Product Description
Specifications
radial drilling machinedrilling machine
radial machine
ISO standard
Z3050X10 radial drilling machine
| ITEM | UNIT | PARAMETERS |
| Max drilling diameter | mm | 32/35 |
| Distance between spindle axis and column | mm | 250/950 |
| Distsance spindle nose and working surface of base plate | mm | 340/1000 |
| Spindle travel | mm | 190 |
| Spindle taper | No. | 5# |
| Range of spindle speeds | r/min | 75-1220 |
| Number of spindle speeds | step | 16 |
| Range or spindle feeds | mm/r | 0.04-3.20 |
| Number of spindle feeds | step | 16 |
| Net weight | kg | 110 |
| Overall dimensions | mm | 1530×700×2100 |
