DTM2000 Drop Weight Impact Testing Machine
DTM2000 Drop Weight Impact Testing Machine
Impact energy: 300J Application: test the impact resistance performance for various pipes materials and plank materials Features: This machine is for impact resistance test of various flats and pipes. It's the necessary test instrument for factories and scientific research institutes. It fully complies with ISO3127,ISO4422 and other relative national standards. Full automatic control allows that automatically preventing a second time impact, automatically crosshead adjusting to zero , automatically specimen adjusting to zero, automatically crosshead returning to a predetermined height, and automatically detecting door closing state controlled, apply SIMENS PLC as a control element. Special control panel and display can satisfy user operation and display requirements, for example, display real-time test data, height, velocity, and impact height setup. This system has power-off protection function, preset impact height data may not lose at power failure. This instrument is applicable to test impact energy of plastics, ceramics, nylons, construction materials and other non-metal pipes and flats. Provide with automatic height control, display and drop control. Lower test platform adjustment is driven by motor automatically, which reduces labor intensity of operator and improves productivity. Technical specifications:
Model |
DTM2203 |
DTM2303 |
DTM2603 |
|||
Maximum impact energy(J) |
2000 |
3000 |
6000 |
|||
Minimum impact energy(J) |
300 |
350 |
750 |
|||
Striker weight (kg) |
70 Two split, 30kg,40kg |
100 Two split, 45kg,55kg |
200 Two split, 100kg,100kg |
|||
Striker weight accuracy |
±2% |
|||||
impact height(mm) |
750mm-2915mm |
750mm-3062mm |
750mm-3062mm |
|||
Striker raising speed |
Approx. 7m/min |
|||||
raising Height resolution |
0.1mm |
|||||
raising Height accuracy |
≤±10mm |
|||||
Hammer blade hardness |
HRC58-62 |
|||||
Hammer-blade curvature radius |
R25±0.1mm |
|||||
Anvils hardness |
HRC58-62 |
|||||
Anvilscurvature radius |
R15±0.1mm,R20±0.1mm |
|||||
Difference between Hammer-blade center and Anvils center |
≤±2.5mm |
|||||
Specimen anvil span |
305mm 100mm |
|||||
Dimension of specimen(mm) |
360X90X25, 130X50X20,130X50X16 |
|||||
Dimension of load frame (mm) |
1080x1240x4300 |
1080x1240x4300 |
1300x1240x4300 |
|||
Power supply |
Five-wire, three-phase 380V 10A |
|||||
Air supply |
0.4~0.7Mpa |
|||||
