Specifications
CSL-Y-type European StandardD. Sample Gap Hydraulic
Electric Broaching
Machine Technology
Hydraulic Electric Broaching Machine Technology
Model: CSL-Y
performance characteristics: Shocks broaching machine sample gap is the only instrument gap for processing the qualified sample except the optical curve grinding machine. Because of processing theory once, the identity of processing the gap is very nice. This broaching machine adopts W18Cr4V manufacturing, high hardness, wear resistance, and every tool can process the sample as many as 20 000. It can meet l GB2106-80 "metal Charpy (V-type notch) impact test method" and GB229-94 "metal Charpy (U-type notch) impact test method", as well as the requirements of domestic and international standard of ASTM E23, ISO148, and ISO083. First two V-or U-notched only need 8 seconds operation, extremely simple and reliable
Gap type | Standard |
V (2mm) were randomly attached | GB229-94,ASTM E23 |
U (2mm) were randomly attached | GB229-94 |
Technical parameters:
Model Parameters | CSL-Y |
V-shape of the sample gap | V, U-type (2,2 mm) |
Processing sample size | 10×10(7.5 ,5)×55mm |
Cutting mode | electric |
Cutting speed | 2.5m/min |
Broach stroke | 350mm |
Broach Materials | W18CV4V |
Power | 380V,0.37Kw |
Dimensions | 650*400*1200 |
Weight | 180 |
Parameters of CSL-Y 1. V-shape of the sample gap, U-type (2,2 mm) 2. Processing the sample size of 10 × 10 (7.5 or 5) × 55mm 3. Cutting mode: electronic 4. Cutting speed: 2.5m/min 5. Broach 350mm stroke 6. Broach Materials: W18CV4V 7. Power: 380V, 0.37Kw 8. Dimensions: 650 * 400 * 1200mm 9. Weight: 180kg
