Specifications
WDW serieselectron universal testing machine
(single space)
with high-performance
and lower price
WDW SINGLE SPACE ELECTRONIC UNIVERSAL TENSILE STRENGTH TESTING MACHINE
WDW SINGLE SPACE ELECTRONIC UNIVERSAL TENSILE STRENGTH TESTING MACHINE
Detailed Applications and Characteristic: WDW series electron universal testing machine (single space) with high-performance and lower price.the single space can increase measuring range by add transducer; highly rigid and lower lexibility. The control system can collect data from force.Displacement.Distortion and speed at the same time.This control system is the first produced in the country .The machine can be used for tensile, compression, bend, shear, peeling, tearing, low circulation test of metal, non-metal material and components. It is in keeping with the testing method and standards of ISO. GB. JIS. ASTM. DIN,the feature as below. 1.adopt Matsushita servomotor, inward no-spaced variable speed transfer system and ball screw, which can precisely transfer force and displacement. nnect by ntrol by computer.or LCD control instrument. 3. multiway 24 bitA/D.Accord with requirement of high-precision and high-standard.Can measure force.Displacement. deformation and so on.. 4.Automatic Control:constant load. Constant nstant stress, constant strain and so on. . 5.kinds of testing curve can been draw:force-displacement.force –deformation. 6.Lower price,highly cost effective,specail suit for small- and medium-sized enterprises to inspect.
WDW SINGLE SPACE ELECTRONIC UNIVERSAL TENSILE STRENGTH TESTING MACHINE
Main technical parameters:
Model & specification |
WDW-5 |
WDW-10 |
WDW-20 |
WDW-30 |
WDW-50 |
WDW-100 |
Measuring range(kN) |
0-5 |
0-10 |
0-20 |
0-30 |
0-50 |
0-100 |
Force rangee(%) |
2-100%FS,we can improve range to 0.4-100%FS base on customer’s requirement |
|||||
Accuracy of indicating value(%) |
±1 |
|||||
Testing speed(mm/min) |
0.5-500mm/min |
|||||
Fractional error of speed(%) |
≤±1 |
|||||
Distortion inaccuracy(%) |
≤±0.5 |
|||||
Displacement measuring error(%) |
≤±0.5 |
|||||
The max.travel(mm) |
450 |
450 |
450 |
450 |
450 |
450 |
Effective space(mm) |
1040 |
1100 |
1100 |
1100 |
1200 |
1200 |
Standard clamp |
Clamp jaws for tensile and compression(Other clamp jaws is optional) |
|||||
Power supply and power(kw) |
1 phase,0.4 |
1 phase,0.4 |
1 phase,0.4 |
1 phase,0.4 |
1 phase,0.75 |
1 phase,0.75 |
External dimension(L×W×H) (mm) |
560×520×1800 |
560×520×1800 |
560×520×1800 |
560×520×1800 |
560×520×1800 |
560×520×1800 |
Weight(kg) |
200 |
220 |
250 |
280 |
350 |
450 |
