Help CenterELECTRONIC UNIVERSAL TESTING MACHINE FOR PLASTIC
Related Products
-
WDW Electronice Universal Testing Machine for RubberNegotiableMOQ: 1 Set -
Electronice Universal Testing Machine for Plastic and RubberNegotiableMOQ: 1 Set
-
WDW-50 Electronice Universal Testing MachineNegotiableMOQ: 1 Set
-
WDW-100 ELECTRONIC UNIVERSAL TESTING MACHINEUS$ 6,901 - 10,163MOQ: 1 Set
-
WDW-S LCD ELECTRONIC UNIVERSAL TENSILE TESTING MACHINE FO RUBBERUS$ 5,737 - 9,198MOQ: 1 Set
Specifications
1.This electronic universal testing machine .is applied in analysis .
and research of
statics property
testing
WDW-100 ELECTRONIC UNIVERSAL TESTING MACHINE
1. Maximum test force: 100KN
2. Accuracy class: 0.5 OR 1
3. Measuring range of test force: 0.4%~100%FS OR 1%~100%FS(full scale)
4. Indicating error of test force: within ±0.5% of indicating value/within ±0.5% of indicating value
5. Resolution of test force: ±1/320000 of maximum test force, grade unchanged and resolution unchanged in whole process
6. Deformation measuring range: 0.2%~100%FS
7. Deformation indicating error: within ±0.5% of indicating value
8. Resolution of deformation: 1/200000 of maximum deformation, up to 1/300000
9. Displacement indicating error: within ±0.5% of indicating value
10. Resolution of displacement: 0.025μm
(2)Control Parameters
1. Tuning range of force control rate: 0.005~5%FS/s
2. Control accuracy of force control rate:
When rate is less than 0.05%FS/s, within ±2% of setting value
When rate is no less than 0.05%FS/s, within ±0.5% of setting value
3. Tuning range of resolution rate: 0.005~5%FS/s
4. Control accuracy of resolution rate:
When rate is less than 0.05%FS/s, within ±2% of setting value
When rate is no less than 0.05%FS/s, within ±0.5% of setting value
5. Tuning range of replacement rate: 0.001~500mm/min
UNIVERSAL TESTING MACHINE
