Rubber Floor Tile Vulcanizing Machine / rubber vulcanizing press / rubber vulcanizer
1.Material of steel plate:
We use hight quality carbon steel Q-235(produce by Jigang Group Co.,Ltd which is a famous company) ,more thicker than other supplier,after shot blasting ,smooth, it is strong enough than common steel
2.Weldment of frame : world technique
Welded together as a whole part,Stewing fire treatment after weldment.
(Carbon dioxide gas shielded welding,alloyed welding wire).
submerged arc welding, VSR treatment after weldment.
3.Piston:
the material of plunger is Chilled cast iron, after polishing,grinding treatment and resist compression test,make the surface smooth,anti-abrasion,durable.
4.Heating way&precision temperature control:
Steam ,oil or Electric (We use high quality hot platen and heating pipe to keep heating stability and uniformity) range of temperature:0-300°C (can be adjustment if you need 400 °C ,we can do it )
Plate temperature tolerance: ±0.1°C (very precise)other factory just is ±3°C
Also we can produce the machine with water cooling system.
There are more advanced technical information as our core patents,and not showed in the description,please send email to us.
|
Parameters/version
|
XLB350*350*2 |
XLB400*400*2 |
XLB500*500*2 |
XLB600*600*2/4 |
XLB750*850*2 |
XLB1000*1000*2 |
Mould closing force |
0.25 |
0.5 |
0.8 |
1.0 |
1.6 |
2.5 |
Hot plate spacing |
125 |
125 |
125 |
125 |
125 |
200 |
Hot plate layer |
2 |
2 |
2 |
2/4 |
2 |
2 |
Plunger stroke |
250 |
250 |
250 |
250/500 |
250 |
400 |
Heating way |
Electricity/stream |
Electricity/stream |
Electricity/stream |
Electricity/stream |
Electricity/Stream |
Electricity/stream |
Main motor power |
2.2 |
2.2 |
2.2 |
2.2 |
3 |
5.5 |
The thermal power |
2.4kw/board |
3kw/board |
3 |
7.5kw/board |
9kw/board |
10.8kw/board |
Size(l*w*h) |
1450*400*1350 |
1600*400*1440 |
1450*690*1818 |
1880*780*1660 |
2100*1010*1900 |
2400*960*2500 |
Weight(kg) |
1200 |
1500 |
1700 |
2500/3100 |
3560/4300 |
8300 |
1.the ture manufacturer,and has our own factory.We are professional in rubber machine.
2.we can design and manufacture all kinds of non-standard machinery according to the costomers' requirement.
3.we are constantly improve our technology. it appeals to many foreigners to visit our company and order our products.
We have professional engineers to provide service after sale and give one year quality guarantee and long-term technical support. If you have any interesting about our products, please tell us, we will give you the best service.
More questions, welcome to contact us~~
