Home > Products > Slitting Machine > JFQ-A CE Approved Film Slitting Machine, Film Slitter, Film Slitting and Rewinding Machine
JFQ-A CE Approved Film Slitting Machine, Film Slitter, Film Slitting and Rewinding Machine
- 5 Set / Sets per Month
- Ningbo
- T/T
-
Leizhan Disc sludge thickener for paper pulp making production line
-
2013HOT SELL Stainless steel structure Disc thickener for paper pulp making production line
-
Disc pulp filter machine of fluting and kraft paper production line
-
Leizhan waste paper recycle equipment ZNP series disc thickener/paper processing equipment/paper pulp machinery
-
disc thickener/paper pulp industrial use
-
disc thickener used for washing and thickening/paper making industry
Product Details
| Condition: | New | Type: | Slitting Rewinder | Computerized: | Yes |
| Place of Origin: | Zhejiang, China | Brand Name: | JIAYUAN | Model Number: | JFQ-A |
| Voltage: | 380V | Power(W): | 2.7KW | Dimension(L*W*H): | 2100MM*1800MM*1200 |
| Weight: | about 1800kg | Certification: | CE | Warranty: | 1 year |
| After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
JFQ-A film slitting and rewinding machine:
Application:
Model JFY-A slitting and rewinding machine applies to all kinds of roll material. such as cellpphane paper, coupon paper, aluminum foil tape, kraft paper tape, double-sided tape, EVA foam, PVC, OPP, PET.
Feature:
1. Machine speed are controlled by electromagnetic.
2. Separate control system, easy to operation.
3. Adopt automatic correction system in unwinding part, in order to slit and rewind accurately.
4. Photocell eye is good for tracking the edge of material and color.
5. Adopts pneumatic shaft and magnetic powder brake for rewinding product.
6. Automatic meter counter.
Main parameters:
1. max. web width: 600mm 1000mm 1300mm
2. max. un-wind diameter: 600mm 600mm 600mm
3. max. re-wind diameter: 400mm 400mm 400mm
4. min. slitting width: 30mm 30mm 30mm
5. working speed: 5-180m/min 5-180m/min 5-180m/min
6. power: 2.7kw 3.5kw 3.5kw
7. weight: about 1800kg about 2000kg about 2200kg
8. overall dimension: 2100*180*1200mm 2100*2000*1200mm 2200*2100*1200mm
PS: any doubts or need video, please call Ms Jessie. Cel: 86-13587591360 Skype: monica913601
Contact Us
- Ruian City Jiayuan Machinery Co., Ltd.
- Contact nameJiayuan Zhu
- Phone86-577-65159218
- AddressNo. 666, Jingye Road, Development Area, Economic Development Zone, Ruian
