Main Characteristics of Foam and Fabric Slitting Machinery:
JFQ-A (Paper and Adhesive Tape Roll Slitting Machine) applies to all kinds of roll slitting, such as cellophane paper, coupon paper, aluminum foil tape kraft paper tape, double side tape, EVA foam, PVC, OPP, PET coil slitting and rewinding. The Foam and Fabric Slitting Machinery adopts the microcomputer control, magnetic powder clutch, auto tension control, center rewinding, and frequency speed regulator.
Technical Parameter of Foam and Fabric Slitting Machinery:
Model |
JFQ-A700 |
JFQ-A1100 |
JFQ-A1300 |
Max Width of Raw Material |
600mm |
1000mm |
1200mm |
Max Diameter of Raw Material |
600mm |
600mm |
600mm |
Min Width of Slitting |
30-600mm |
30-600mm |
30-600mm |
Speed of Slitting |
5-180m/min |
5-180m/min |
5-180m/min |
Max Speed |
200m/min |
200m/min |
200m/min |
Slitting and Rewinding Precision |
±0.2mm |
±0.2mm |
±0.2mm |
Total Power |
2.7kw |
3.5kw |
3.5kw |
Suitable Power Supply |
380V/50Hz |
380V/50Hz |
380V/50Hz |
Weight |
1800kg |
2000kg |
2200kg |
Overall Dimension(L×W×H) |
2100×1800×1200mm |
2100×2000×1200mm |
2200×2100×1350mm |
