Single Shaft Jumbo roll roland vinyl cutter
Application
Suitable for Cutting machine for adhesive tape manufacturing
For example: double side tape, cloth tape, masking tape and other special tapes
Features:
1.Main Motor: Cutting shaft and circular blade are driven by A.C motor with inverter control, which able to set RPM and running direction obverse/reserve on different requests.
2.Central Control: Central control system is CPU, which can cut various sizes on one log roll by changing modes automatically.
3.Display Mode: All functions are operated under LCD touch panel control, which is operator friendly and easy for data setting.
4.Width Setting: Width setting is controlled by servomotor with ball screw and guide rails to make accuracy movement.
5.Cutting System: Knife feeding is controlled by servomotor, which can do three-speed cutting.
6.Knife Angle Adjustment: Cutting angle can be changed automatically for making roll surface smoothly.
7.Shaft Change: Three kinds of cutting shafts for optional using on this machine, which use quick changing shaft according to different material.
Specification:
Machine Width: 1M-1.6M
Max. Cutting O.D: 350mm
Cutting Core I.D: 1"-3"
Min. Cutting Width: 2mm
Technical Parameter:
Model |
JY-A400 Tape Roll Slitter |
Max Length of Raw Material |
1400mm |
Max Unwind Diameter |
400mm |
Range of Slitting Width |
0.5mm-1350mm |
Slitting Precision |
±0.03mm-±0.12mm |
Slitting Way |
Servo Knife |
Total Power |
10kw |
Overall Dimension |
3050×1250×1500mm |
Installation: the seller will send for an engineer for installation if customer need. The charge of accommodation, food and round air-tickets, salary USD60 per day for engineer should be paid by the buyer. The normal period of installation is within 3 days, the buyer needs to delay unless special condition.
Delivery Time: within 60 working days after we receive the deposit
(Noted: Machine can be shipped after Inspection only.)
Warranty Time: 1 year
Packing: wooden case
