Specifications
plasma cutter machine agent 1325S1.plasma cutting machine,Good quality
2.plasma cutter machine with high accracy
plasma cutter machine agent 1325S
Machine Size |
1850*3000*1300 |
MM |
Working Area |
1300*2500 |
MM |
Material Thickness |
0-25 |
MM |
Cutting Speed |
0-20000 |
MM/Min |
Power |
8500 |
W |
Input Voltage |
3-Phase 380V/50Hz |
V/Hz |
Plasma Current |
40A , 60A, 100A, 120A |
A |
File Transfer |
USB Interface |
|
ARC Mode |
Non-Contact ARC |
|
Net Weight |
3000 |
KGS |
plasma cutter machine agent 1325S
Functions and Applications:
Structure |
Adopted the design of double light beam to ensure the good rigidity, low weight and low inertia. |
Feature |
Gantry type structure, Y axis apply the helical high rack and pinion . X axis adopts high accurate ball screw transmission. |
Merits |
Small cutting incision , clear , no dregs , avoiding the secondary repair again. |
Material |
Iron Sheet, Aluminum Plates, Zinc Plates, White Iron Sheet, Titanium Plates and other metal processing. |
Software |
Wentai, Artcam, Beihang Haier, Type3, or through the software switcher to read AUTOCAD to form DXF farmat. |
plasma cutter machine agent 1325S
Service:
Warranty |
One year |
Technical Support |
All Life |
plasma cutter machine agent 1325S
Trading Terms:
Payment Terms |
TT / , L/C |
Delivery Terms |
FOB Shanghai or Nanjing (Only Domestic). |
Payment Condition |
Payment 70%in advance before shipping to the port (domestic) pay off the balance. |
Packing |
exported standard pack |
Supply Capacity |
200Sets / Month |
plasma cutter machine agent 1325S
Company and workshop
plasma cutter machine agent 1325S
sample display
plasma cutter machine agent 1325S
Our team
Guarantee |
One year |
Technical Support |
All Life ( If machine is blocked, please contact us immediately and we will arrange for technical engineer to solve ). |
plasma cutter machine agent 1325S
Package:
plasma cutter machine agent 1325S
Why you choose Nanjing Chaohan CNC machine?
1. Our Company is specialized in manufacturing and exporting CNC router and laser machine.
We have much export experience. And we will provide the high quality machines with competitive prices.
2. Our machines are widely used in almost all the materials and industries.
3. we provide you one-stop services, including Online Negotiation, Order Confirmation, Delivery and Transport, Installation Guidance, and After Sales Service
4. We can manufacture the machines in shorter time according to your requirements.
Note:If you are not sure which machine is suitable, please tell me the following questions,
i will recommend the most suitable machine to you.
1) what materials do you want to engrave or cut?
2) what's the max. size of the materials and your products? (Length*Width*Thickness)
