The Air Cannon developed by our company have most advanced workmanship in China , at the same time,the most automatic production linewas introduced.Furthermore, we have the most complete technology researching and developing, management team. Our company has perfect R&D staff and management team.Our company possesses perfect domestic and international instructors and after-sales service,as well as lowest price advantage.
Different kinds of air cannon we can offer
1,New-fashioned Surfacing Air Cannon
The Air Cannon produced by our factory adopts the brand-new galvanizing craft: The whole set Air Cannon can prevent the cannon body from rust and lengthen the life-span effectively after the new-fashioned galvanizing treatment. Meanwhile, because of the selection of reasonable galvanizing craft parameter, our new-fashioned galvanizing Air Cannon can prevent surface collision and scratch effectively during storage and transport.
2,New-fashioned Grate Cooler Air Cannon
Our company ,based on the principle of "Customer First!”, developed new-fashioned High Temperature Resistant piston-cylinder system considering the special hot environment sintering furnace such as cement preheated, thermal power plant and steel mill; Our cylinder is made of high-performance stainless steel, our piston also uses suitable material and hot treatment, which make our Air Cannon can work under 1000 centigrade degrees.
3,New-fashioned Twin Nipple Air Cannon
Our company rely on many years experience of site use, in-depth study the usage of complicated bunker, combined with our technical strength, developed new-fashioned twin nipple Air Cannon. Two nipples were designed which located respectively at left and right seal heads, furthermore, concurrent control was used, i.e. We can control one single nozzle or control two nozzles at the same time. If it was used in complicated bunker clear process, it can not only reduce cost but also clear effect is obvious.
4.New-fashioned Split Air Cannon
To better the down-hole clear service for the coal mine, our company organizes professionals to go into down-hole of mine, combined practical production demand, we developed new-fashioned split Air Cannon, which solved the limited down-hole space problem for the mine. New-fashioned split Air Cannon can serve several purposes. Nozzles can be installed dispersedly so that the steel pipe can put into various bins, meanwhile, cannon body can be fixed at porthole or suitable place, and it is very convenient for down-hole work.
5. New-fashioned Mould Bowl Air Cannon
In the bunker with a large number of powder material , its stuff has large amount of dust.It is easy to reach cylinder through the barrel, influence the movements of the piston in the air cylinder, causing card phenomenon. To solve this problem,our company developed the mould bowl Air Cannon on the basis of existing products, it can solve the the effluence of smashed material and dust effectively.
6.New-fashioned Stainless Steel Air Cannon
Air Cannon is made of Whole high-performance steel, with new craft, can improve every performance index of the Air Cannon.Designed primarily to applicable special devices such as the large-scale flour, mill,pharmaceutical factory, feed mill, food processing factory, etc.
7,Categories of Air Cannon
Because the Air Cannon is applicable in extensive range, the applicable environmental condition is complicated, install space varies much. Our company produces and develops serial A type, B type, C type Air Cannon according to national relevant regulations. Users can choose suitable types as per the location and space of bunker.
8,Newfashioned Hydraulic Cleaner
Newfashioned Hydraulic Cleaner developed by our company has logic control function aimed at feeder machine and material hopper ,meanwhile,this equipment is also Electric-Hydraulic-Automatic mechatronics cleaner .It plays a positive role in preventing the boiler from fire and protecting feed machine, abrasive machine
The Air Cannon and Cleaner Equipment developed by our company have most advanced workmanship in China , at the same time,the most automatic production line was introduced.Furthermore, we have the most complete technology researching and developing, management team. Our company has perfect R&D staff and management team.Our company possesses perfect domestic and international instructors and after-sales service,as well as lowest price advantage.
GKQP-B Air Cannon Characteristics
1.High Temperature
Body of Air Cannon valve internal moving parts ang no rubber seals.Particularly suitable for grate cooler, kiln slope, smoke room and high temperature operating requirements, substantially reducing maintenance costs, significantly extended service life.Body moving parts (piston) inelastic body.
2.Self-lubricating
Unique design cylinder and piston bearings without lubrication.
3.Low maintenance
25 million times without failure, removal of the replacement parts is very conventient.
4.Long life
Key components used to optimize the design of modern design, good air tightness.
5.Strong spray drying
Spray dry strengh increased by 10% compared with similar products.
6.Easily compatible with
Dual connection method, the body of Air Cannon value with other brands of Air Cannon gas cylinders connected to reduce the cost of the user to upgrade.
Primary Technical Paremeter
No. |
MODEL |
CAPACITY (L) |
DIAMETER (mm) |
EXHAUST DIMAERER (mm) |
SLINGER HOLE (mm)
|
AIR INTAKE ('') |
SAFE VALVE SEAT ('') |
WORKING TEMPERATURE (℃) |
WORKING PRESS (mpa) |
INPACT FORCE (N) |
EXPLOSION ENERGY (N) |
WEIGHT (kg) |
| 1 | GKQP-B-75 | 75 | 410 | 108 | 16 | G1/2 | ZG3-8 | -40~1200 | 0.4-0.8 | 4500-10000 | 123600 | 50 |
| 2 | GKQP-B-100 | 100 | 410 | 108 | 16 | G1/2 | ZG3-8 | -40~1200 | 0.4-0.8 | 5800-12600 | 129000 | 60 |
| 3 | GKQP-B-150 | 150 | 510 | 108 | 16 | G1/2 | ZG3-8 | -40~1200 | 0.4-0.8 | 6800-14600 | 221000 | 70 |
| 4 | GKQP-B-170 | 170 | 510 | 108 | 16 | G1/2 | ZG3-8 | -40~1200 | 0.4-0.8 | 8800-15600 | 251000 | 75 |
| 5 | GKQP-B-200 | 200 | 510 | 108 | 16 | G1/2 | ZG3-8 | -40~1200 | 0.4-0.8 | 9800-17600 | 271000 | 85 |
| 6 | GKQP-B-300 | 300 | 610 | 108 | 16 | G1/2 | ZG3-8 | -40~1200 | 0.4-0.8 | 12000-19600 | 32100 | 110 |
ZS-12 Type Air Cannon Primary Technical Paremeter
Technical Requirements:
1.Except the indicator, the form and size of joints should be consistent with the rule of GB085-088-88.The jointing height is equal to the thickness of relatively thinner one and all need to be jointed together.
2.When installing,ensure a flat and even surface of base angle iron and close to bin.
3.After installation of this apparatus, completely get rid of rusts on supports.Prime and make surface paint.The color and brand issu biect to users themselves.
Notes:
1.The installation orientation of air cannon shall be symmetry or spiral, which depends on users and installation personnel.
2.The products adopt hanging or saddle installation.Shorten the length of vent-pipe as much as possible and do not utmost to set up 90°celbows.
3.In case of small space, elbows can be set up or pipe unit can be lenghthened in starting parts but they should perpendicular.
Puyang Zhongshi Group Company Ltd was founded in 1996,which is the restructured enterprise of Central Plains oilfield branch company of SINOPEC . The company registered capital is 6083 million yuan,with annual output value 200 million yuan, 580 employees, including more than 160 technical and administrative staff. Oil machinery is our main products, the leading products include pumping unit,subsurface sucker rod pump, wellhead (Christmas Tree), pressure vessels,drilling solid control series products and cementing accessories, We had attained ISO 9001 in 1998 and API Certificates in 2002 .
All products purchased in our company are guaranteed to keep in good repair for one year. If quality problems happen in guarantee period, our company will maintain for free. Additionally, our company provides technical support and fittings for life. After-sales service isn't restricted by time and we will assign technical personnel to solve your problems immediately after receiving telephone and hear feedback idea of users and deal with them in time. If you are caught in some problems when using our products, welcome to contact us at any time.
