Portable Lift, 1000lbs Load Capacity, Lift Height 15',vertical winch
1.Model Number: |
ATQ-02 |
2.Power Source: |
Electric 1200W |
3.Voltage: |
AC 100-240V/50/60HZ |
4.Lifting Height: |
4.6M |
5.Wire rope dia: |
5.8mm |
6.Speed: |
5m/min |
7.Load Capacity: |
250KGS/500lbs |
8. Net weight: |
7kg |
9.Motor: |
Series motor |
10. Protection: |
Overload protection and overheat protection, remote control adds a third protection. |
11.Certification: |
CE and ISO |
12.Color: |
Blue,Yellow,Red or According to Customer Request |
13.Logo: |
AiboLift |
14.OEM: |
Available |
15.MOQ: |
216sets Small trial order is acceptable |
16.Production Capacity: |
5000sets/Month |
17.Sample Lead time: |
5days for regular item |
18.Packing: |
Color Box or Standard Export Cartons |
19.Delivery: |
By express courier / by air / by sea |
20.Payment: |
T/T |
The capstan winch is a tough, highly portable unit that is perfect for the likes of utility machinery
installation, overhead line crews, farm improvement, and transformer replacement.
with its dynamic brake that holds in position under load--even when powered down--it can be used both as a winch (for pulling) and as a hoist (for lifting and holding).
The light duty winch with remote control that allows you to move heavy items into place
with minimum effort. It will help get the job done easier, faster, and with less manual labor.
Features
+ Protection hook, high tensile alloy galvanized wire rope ensures easy installation and safe
working.
+ Sealed, pendant-style remote with 8M lead, cost less manual labor.
+ Strength Al-alloy shell makes it weight light, stand wear and tear.
+ Temperature protection system extend a longer service life.
+ All gears are made from high quality Alloy steel with hard surface, allowing it to work in a
sealed oil bath for a long time.
Experienced but Keep Original
Over 23 years in hardware manufacture and continue developing new styles in electric hoist and winch.
OEM is available due to skilled engineers and trained staffs.
Cost Down, Quality Up
Independently manufacture and export by us that will help you cost saving and more competitive in the market.
Only suppliers with good fame will we select to cooperate from raw material to packing.
Mature management ensures a smooth production.
Testing systems are established to ensure finished product are in good quality, including hoisting test, pulling test, high voltage resistance test and earth resistance test.
These build up our confidence.
Service within 24 hours
We promise to feedback within 24 hours from Monday to Saturday.
Pulling, Lifting, Energy Saving! Easy you take, Safety we care!
Q: What is our factory product range?
A: Mini electric wire rope hoist, suspending electric hoist, wire rope winch, vertical lifting AC winch remote control etc.
Q: What information should I provide if I want to order the products?
A:
1) Product information: Quantity, Model No. , Specification (capacity, lifting height, voltage, size, material, color and packing requirements),
2) Delivery time required.
3) Shipping information: Company name, Address, Phone number, Destination seaport/air port.
4) Forwarder's contact details if there is any in China.
Q: How about your payment terms?
A: For trial sample order, 100% advance, via Western Union is preferred.
For bulk order, 30% deposit, with the balance before delivery, via TT.
Q: Can I use our own logo?
A:Yes, we can produce by using your own logo.
Q: What’s the sample policy?
A: We can send you 1pc of sample for your test, but you need to pay for the sample fee and delivery expenses, as it's our company's rule. Pls contact us for the sample details.
