Replacement for old-fashioned come-a-longs and chainfalls,new type handheld electric winch
It's a portable electric winch(manual one, we also have others with remote control) with strong wire rope. They can lift, pull and place loads across distances without extra efforts. The galvanized wire rope winches are suitable for use in various applications and are the ideal solution for professionals.
It will help get the job done easier, faster, and with less manual labor.
As soon as the operator stops pulling, the motor stops and the drum stops turning, preventing rope damage.
Features
- Light weight for quick installation
- Easy to use, light duty, and powerful
- Temperature protection
- Overload protection
- Equipped with strong electric motor, powerful in pulling and lifting
- High quality aircraft-grade alloy galvanized wire rope
- Unique motor heat dissipation device, providing a longer service life
1.Model Number: |
ATQ-03 |
2.Power Source: |
Electric 1200W |
3.Voltage: |
AC 100-240V/50/60HZ |
4.Lifting Height: |
8M |
5.Wire rope dia: |
4.8mm |
6.Speed: |
5m/min |
7.Load Capacity: |
250KGS/550lbs |
8. Net weight: |
7kg |
9.Motor: |
Series motor |
10. Protection: |
Overload protection and overheat protection |
11.Certification: |
CE and ISO |
12.Color: |
Blue,Yellow,Red or According to Customer Request |
13.Logo: |
AiboLift |
14.OEM: |
Available |
15.MOQ: |
108 sets |
16.Production Capacity: |
1250 sets/Month |
17.Sample Lead time: |
5 days for regular item |
18.Packing: |
Color Box or Standard Export Cartons |
19.Delivery: |
By express courier / by air / by sea |
20.Payment: |
T/T |
Q: What is our factory product range?
A: Mini electric wire rope hoist, suspending electric hoist, wire rope winch, vertical lifting AC winch remote control etc.
Q: What information should I provide if I want to order the products?
A:
1) Product information: Quantity, Model No. , Specification (capacity, lifting height, voltage, size, material, color and packing requirements),
2) Delivery time required.
3) Shipping information: Company name, Address, Phone number, Destination seaport/air port.
4) Forwarder's contact details if there is any in China.
Q: How about your payment terms?
A: For trial sample order, 100% advance, via Western Union is preferred.
For bulk order, 30% deposit, with the balance before delivery, via TT.
Q: Can I use our own logo?
A:Yes, we can produce by using your own logo.
Q: What’s the sample policy?
A: We can send you 1pc of sample for your test, but you need to pay for the sample fee and delivery expenses, as it's our company's rule. Pls contact us for the sample details.
Experienced but Keep Original
Over 23 years in hardware manufacture and continue developing new styles in electric hoist and winch.
OEM is available due to skilled engineers and trained staffs.
Cost Down, Quality Up
Independently manufacture and export by us that will help you cost saving and more competitive in the market.
Only suppliers with good fame will we select to cooperate from raw material to packing.
Mature management ensures a smooth production.
Testing systems are established to ensure finished product are in good quality, including hoisting test, pulling test, high voltage resistance test and earth resistance test.
These build up our confidence.
Service within 24 hours
We promise to feedback within 24 hours from Monday to Saturday.
Pulling, Lifting, Energy Saving! Easy you take, Safety we care!
