Help CenterOptical Low Pass Filter OLPF
Related Products
Specifications
We produce various kind of Optical Low Pass Filter(OLPF), including single piece and multi pieces bonding.1,We produce various kind of Optical Low Pass Filter(OLPF), including single piece and multi pieces bonding, suitable for used in digital imaging products, such as Digital Camera, Monitor, Digital Video, ect.
2,Technical Specification:
beam-splitting characteristic(Also can add ITO conductive coating and hydrophobic coating, according to customer requirement);
integrated beam-splitting characteristic: T=50% point, shortwave side 390(+10,-15)nm, long wave side 640(+15,-10)nm
340nm-370nm Tabs85% 450nm-500nm Tabs>90% 500nm-540nm Tabs>88% 540nm-560nm Tabs>87%
560nm-580nm Tabs>80% 600nm Tabs>72% 650nm Tabs>15% 660nm Tabs>5% 700nm-1100nm Tabs<1%
Surface quality technical requirement: A,Foreign matter, air bubbles, scratch, and pinholes, etc through clear aperture of AR coating and inside cement layer, size should under 15μm. B,Foreign matter, air bubbles, scratch, and pinholes, etc through clear aperture of IR coating, size should under 20μm. 3,Production capacity:2 million pieces /year;
Send Inquiry to This Supplier
