- Commodity : Chicken egg poultry farm prosessing machine from China
- Capacity:5000eggs/hour
- Material: Stainless steel 304
- Dimension(L*W*H): 8000*1700*1300mm
- Power: 12.5KW
- Voltage:380V
- Function: cleaning, drying ,coating and grading
- Optional:
a) Vacuum egg lifter
b) Printing
c) UV
d) Candling
Flow chat
Instruction
a) Vacuum egg lifter
First, Eggs are sucked onto the roller of egg loading unit by a vacuum egg lifter (1*6=6 eggs each suck). The vacuum egg lifter is used to help workers to load eggs onto the egg machine more easily.
b) Cleaning
Eggs are put by vacuum egg lifter on the roller of cleaner, will be aligned automatically, so as to guarantee all the eggs enter the egg cleaning machine in good order. There are 2 parts of bush in this type of egg cleaning machine, egg will be cleaned with warm water by the first brush.
c) Drying
Water on the eggs will be swiped off by the second brush, and at same time eggs will be dried by strong heated wind generated by drying fan.
d) Printing
After being dried, eggs will be printed by the cartridge printer, the position where code is printed is in the middle of the eggs (between the bigger head and the smaller head).
e) Coating(food-grade oil spraying)
After being printed, the eggs will enter the egg oil spraying part where
eggs will been coated a thin layer of food-grade mineral oil thus preventing the eggs from being intruded by bacteria and keep the eggs fresh for a longer time.
f) UV sterilizing:
Next, coated eggs will turn into UV sterilizing equipment which has been installed with a cover. After that the eggs will enter the roller of grader.
g) Candling
Candler with LED light source has been installed on the roller of grader to help operators to check whether there is any damage on the eggs. For example eggs with cracks, eggs with black core, eggs having gone bad can be selected out by hand
h) Grading
After candling, eggs will enter the weighing part of grader. Egg grading machine can at most separate eggs into 5 grades. Eggs of different weight fall down onto to different lanes of the egg collecting board of grader.
i) Package
At last, workers should collect eggs from different lanes into different stacks of egg trays manually. Then workers can pack egg trays into boxes for sale.
Why buy from us ?
long history
we are one of the leader of egg machinery manufacturer of 8 years in the development and research of egg machines in China. our products are hottest sale in China and abroad ,and
also won a goode feedback from our clients.
high quality products
Our products is highest quality and reasonable price ,it has got the CE cetificate and sale good in our country and abroad ,we have won many honors.
strong package:
we usually packed this kinds of machine in a sealed wooden case to prevent unexpected damage due to rough handling in transit.
delivery on time
we have our own product factory ,when receive your order we can arrange production immediately, besides , we have long-term cooperated shipping company to enable transporting your goods safely and timely.
Our services
We provide life-long service for machine
We give you some spare parts for free along with the delivery of the machine
If required we can appoint our engineers to serve for you onsite.
