Economical Single Shaft Vibirating Screen for Ore Dressing

Economical Single Shaft Vibirating Screen for Ore Dressing photo-1
US$ 1,800 - 8,800 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Gravity Separator
Place of Origin:
Jiangxi, China
Payment & Shipping
Payment Methods:
Port of Shipment:
Xiamen
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Type Gravity Separator
Place of Origin Jiangxi, China
Brand Name MX famous brand
Certification ISO9001:2000

Specifications

The equipment is widely used in mineral processing and ore dressing to screen material with granule from coarse to ultrafine

VIBRATING SCREEN

Industrial vibrating screen are used as standard practice where large capacity and high efficiency of screening are desired.



Vibrating screen for stand alone or multiple installations are manufactured in a wide range of sizes for varying application and production demands. Each unit is compatible with all screening systems and can be integrated into existing and current processing plants. We offer wide range of vibrating screen and vibrating separator like industrial vibrating screen, vibrating screen separator, vibrating screens, industrial woven wire screens, woven wire screen.
These industrial vibrating screen and vibrating screen separator available in industrial leading price.



Advantages of Vibrating Screen and Vibrating Separator include :

  • Accuracy of sizing
  • Increased capacity per square foot
  • Low maintenance cost per ton of material handled
  • Saving in installation space and weight.

Typical applications are Wet and Dry products for producers who demand constant high production. To maximize efficiency our company has produced an advanced range of options, which include: Variable Angling, Spray Bars fitted on all decks.



Technical parameter:

Model Screen  size (mm) Screen  layer (layers) granularity(mm) Sieve Size (mm) Vibrating frequency (times / min) Dual amplitude (mm)  Gradient(degrees)
DD918 900 * 800 1 ≤ 60 1,2,3,6,8,10,13, 16,20,25 1000 5-6 15-25
2DD918 900 * 1800 2 ≤ 60 "" " " "
SZZ1918 900 * 1800 1 1,2,3,6,8,10,13, 16,20 " " "
SZZ2918 900 * 1800 2 "" " " "
ZD1224 1200 * 2400 1 6,8,10,13,13,16 850 6-7 "
2ZD1224 1200 * 2400 2 20,25,30,40 " " "
DD612 600 * 1200 1 1,2,3,6,8,10 1000 5-6 "
2DD612 600 * 1200 2 13,16,20,25 "





installating

pattern

processing

capability(stere/h)

motor

model

motor

power

(kw)

eight(ton)

overall size(mm)



suspensory 10-30 Y100L-4 2.2 0.44 2150x1418x575
suspensory 10-30 Y100L-4 2.2 0.6 2200X1418X630
suspensory 5-25 Y100L-4 2.2 0.56 2150X1358X575
suspensory 5-25 Y100L4 2.2 0.68 2189X1358X700
base 70-210 Y112M-4 4 1.13 2500X2150X1340
base  70-210 Y112M-4 4 1.15 2600X2200X1370
suspensory 10-20 Y90L-4 1.5 0.34 1370X890X430
suspensory 10-20 Y90L-4 1.5 0.36 1370X890X530
