Widely Applicable Best Quality Tungsten Spiral Classifier

Widely Applicable Best Quality Tungsten Spiral Classifier thumbnail-1
Widely Applicable Best Quality Tungsten Spiral Classifier thumbnail-2
Widely Applicable Best Quality Tungsten Spiral Classifier photo-1
Widely Applicable Best Quality Tungsten Spiral Classifier photo-2
US$ 10,000 - 100,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Sprial Separator
Production Capacity:
675-1080t/d
Contact Supplier Request Quote Chat Now
Jiangxi Mingxin Metallurgy Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Xiamen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Sprial Separator
Production Capacity 675-1080t/d
Place of Origin Jiangxi, China
Brand Name MINGXIN
Model Number FG-10
Voltage 220V-480V
Power(W) 5.5KW
Weight 3000kg-10000kg
Certification ISO9001:2000
Warranty 12 Months
After-sales Service Provided Engineers available to service machinery overseas

Spiral classifier is widely used to control material size from ball mill in the beneficiatio process, separate mineral sand and fine mud in the gravity concentration, and clean mud and water in washing mineral process. Spiral classifier has features of simple structure, stable performance and easy operation, etc.



Working principle:

Spiral classfier is a kind of classfying machine that classfies big and small mineral granules. It works based on the fact that different granules(with various size and weight) sink at different speed in liquid. It can filter powders grinded from  mill and rotate the coarse materials to feeding hole of the mill and discharge filtered fine materials through the overflow pipe. The chassis of the spiral classifier is made of channel steel and the main machine is welded by armor plate. The water inlet and the shaft head come with cast iron sleeve,  which are robust and abrasion resistant. The equipment is available both in manual and auto mode.

widely applicable best quality Tungsten spiral classifier

Specifications of Spiral Classifier


Model

Spiral diameter
(mm)

Spiral rotation speed
(r/min)

Trough length
(mm)

Motor power(kw)

Capacity(t/d)

Weight
(t)

For driving

For lifting

Return sand

Overflow



FG-7.5

750

6-10

5500

3.0

Manual

340-570

65

2.7

FG-10

1000

5-8

6500

5.5

Manual

675-1080

110

4.43

FG-12

1200

5-8

6500

5.5

1.5

1170-1870

155

8.7

FG-15

1500

4-6

8400

7.5

2.2

1830-2740

235

12.5

FG-20

2000

4-6

8400

11

2.8

3240-5400

400

20.5

FG-24

2400

3.6

9210

15

3.0

4650-7450

580

25.6

FG-30

3000

3.2

1250

22

4.0

11625

890

37.7

2FG-12

1200

5-8

6500

5.5×2

1.5×2

2340-3740

310

14.0

2FG-15

1500

4-6

8400

7.5×2

1.5×2

3660-5480

470

21.1

2FG-20

2000

3-5.5

8400

11×2

2.8×2

7780-11880

800

36.5

2FG-24

2400

3.6

9210

15×2

3×2

13600

1160

46.8

2FG-30

3000

2-3.2

12500

22×2

4×2

14600-23400

1785

73.0



For more detailed information concerning our company and products pls visit .
