UL1095 Hook-up Wire

UL1095 Hook-up Wire thumbnail-1
UL1095 Hook-up Wire photo-1
US$ 0.05 - 0.2 MOQ: 610 Meters
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
NANGUDI
Model Number:
UL1095
Contact Supplier Request Quote Chat Now
Dongguan Nangudi Electronics Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
HK etc
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name NANGUDI
Model Number UL1095
Type Insulated
Application Other, internal wiring of appliances, Electrical Equipment,circuit
Conductor Material Other, bare copper,tinned copper
Conductor Type Other, solid,stranded
Insulation Material Other, PVC, PVC

Specifications

UL1095 Hook-up Wire
1,UL approval.RoHS compliant.
2,ISO9001:2008 certified manufacturer.
3,100% inspection.

UL1095 Hook-up Wire



Packaging & Delivery

Packaging Detail: 2KFT(610M)/Coil
Delivery Time: 3-5 workday after payment

Product Description:

1. Tinned, annealed,stranded or solid copper conductor.

2. Color-coded PVC insulation.

3. Uniform thickness of wire to ensure easy stripping and cutting.

4. Passes UL VW-1&CSA FT1 vertical flame test.

5. Executed standard: UL758, UL1581, CSA22.2.

6.Resist to acids,oils,alkalies,moisture and fungus.



Product Construction:



UL Style & CSA Type Conductor Insulation
Thickness		 Overall
Diameter		 Standard Put-up Conductor
Resistance at 20°C
AWG No/mm mm mm Ft/coil M/Coil Ω/KM
UL1095
(Stranded)		 30 7/0.100 0.3 1.00 2000 610 381.00
28 7/0.127 0.3 1.10 2000 610 239.00
26 7/0.160 0.3 1.20 2000 610 150.00
24 11/0.160 0.3 1.30 2000 610 94.20
22 17/0.160 0.3 1.40 2000 610 59.40
20 21/0.178 0.3 1.60 2000 610 36.70
18 34/0.178 0.3 1.90 2000 610 23.20
16 26/0.250 0.3 2.20 2000 610 14.60
UL1095      (Solid) 30 1/0.254 0.3 0.9 2000 610 361.00
28 1/0.320 0.3 1.00 2000 610 227.00
26 1/0.404 0.3 1.05 2000 610 143.00
24 1/0.511 0.3 1.20 2000 610 89.30
22 1/0.643 0.3 1.30 2000 610 56.40
20 1/0.813 0.3 1.50 2000 610 35.20
18 1/1.024 0.3 1.70 2000 610 22.20
16 1/1.290 0.3 1.90 2000 610 14.00



Product Pictures:



UL1095 Hook-up Wire
