80C 30V UL20554 Telephone Cable

80C 30V UL20554 Telephone Cable thumbnail-1
80C 30V UL20554 Telephone Cable photo-1
US$ 0.05 - 0.2 MOQ: 3050 Meters
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
NANGUDI
Model Number:
UL20554
Contact Supplier Request Quote Chat Now
Dongguan Nangudi Electronics Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
HK etc
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name NANGUDI
Model Number UL20554
Type Insulated
Application Other, internal wiring of appliances, Electrical Equipment,circuit,automotive
Conductor Material Other, bare copper,tinned copper
Conductor Type Other, solid,stranded
Insulation Material Other, PUR

Specifications

80C 30V UL20554 Telephone Cable
1,UL approval.RoHS compliant.
2,ISO9001:2008 certified manufacturer

80C 30V UL20554 Telephone Cable



Packaging & Delivery:

Packaging Detail: 2KFT(610M)&1KFT(305M)/Coil
Delivery Time: 5-7 workdays after payment

Product Characteristic :



1)  Tinned,annealed,stranded or solid copper conductor.

2)  Resistant to haet,cold,abrasion,tinned flexibility,cut-through,oil,ect.

3)  Passes UL VW-1 & CSA FT1 vertical flame test.

4)  Executive Standard:UL758,UL1581,CSA22.2.



 Product Construction:



UL Style& CUL Type Cores Conductor Insulation
Thickness		 Nom.Dia Shield Coverage Jacket Thickness Overall
Dimeter		 Conductor
Resistance at 20°C
AWG No/mm mm mm % mm mm Ω/KM
UL20554
CUL
(Stranded)		 2C 30 7/0.100 0.23 0.80 >=65 0.38 3.20 381.00
28 7/0.127 0.23 0.90 >=65 0.38 3.40 239.00
26 7/0.16 0.23 1.00 >=65 0.38 3.60 150.00
24 11/0.16 0.23 1.10 >=65 0.38 3.80 94.20
22 17/0.16 0.23 1.30 >=65 0.38 4.20 59.40
20 21/0.178 0.23 1.50 >=65 0.38 4.60 36.70
18 34/0.178 0.23 1.80 >=65 0.38 5.20 23.20
16 26/0.25 0.23 2.10 >=65 0.38 5.80 14.60
UL20554
CUL
(Stranded)		 3C 30 7/0.100 0.23 0.80 >=65 0.38 3.40 381.00
28 7/0.127 0.23 0.90 >=65 0.38 3.50 239.00
26 7/0.16 0.23 1.00 >=65 0.38 3.80 150.00
24 11/0.16 0.23 1.10 >=65 0.38 4.00 94.20
22 17/0.16 0.23 1.30 >=65 0.38 4.40 59.40
20 21/0.178 0.23 1.50 >=65 0.38 4.80 36.70
18 34/0.178 0.23 1.80 >=65 0.38 5.50 23.20
UL20554
CUL
(Stranded)		 4C 30 7/0.100 0.23 0.80 >=65 0.38 4.80 381.00
28 7/0.127 0.23 0.90 >=65 0.38 5.10 239.00
26 7/0.16 0.23 1.00 >=65 0.38 5.30 150.00
24 11/0.16 0.23 1.10 >=65 0.38 5.50 94.20
22 17/0.16 0.23 1.30 >=65 0.38 6.00 59.40
20 21/0.178 0.23 1.50 >=65 0.38 6.50 36.70
UL20554
CUL
(Stranded)		 5C 30 7/0.100 0.23 0.80 >=65 0.38 5.00 381.00
28 7/0.127 0.23 0.90 >=65 0.38 5.30 239.00
26 7/0.16 0.23 1.00 >=65 0.38 5.60 150.00
24 11/0.16 0.23 1.10 >=65 0.38 5.80 94.20
22 17/0.16 0.23 1.30 >=65 0.38 6.40 59.40
UL20554
CUL
(Stranded)		 6C 30 7/0.100 0.23 0.80 >=65 0.38 5.30 381.00
28 7/0.127 0.23 0.90 >=65 0.38 5.60 239.00
26 7/0.16 0.23 1.00 >=65 0.38 5.90 150.00
24 11/0.16 0.23 1.10 >=65 0.38 6.20 94.20




Product Pictures:



80C 30V UL20554 Telephone Cable
