STA 1800C muffle furnace zirconia dental furnace
STA-175KM -1200 laboratory high temperature muffle furnace with 1200C 1400C 1700 1800C which consists of super high quality alumina fiber brick with ZrO2 liner and high quality MoSi2 heating rods which can be used up to 1800°C. Temperature is controlled by high precision SCR (Silicon Controlled Rectifier) digital controller with accuracy +/-1°C and 30-50 segments programmable. It is widely used in materials annealing, sintering, Gravimetric analysis, Sintering, Quantitative analysis, Heat treating, Glass preparation and Smelting.
Characteristics:
1.Unique door design,safe and easy door operation, toen sure the high temperature inside that the heat does not leak.
2.high-precision digital display meter,temperature control system with microcomputer chip processor with PID regulation characteristics, time set, temperature difference correction, over-temperature alarm and other functions, high precision temperature control.
3.The furnace cavity is baked by the high temperature refractories toen sure durability.
4.excellent door seal to make the heat loss to be minimum, increase the temperature uniformity in the furnace.
Regular specifications
| Product name and model | STA-175KM-1800 Box Type Muffle Furnace |
| Chamber size(WxHxD) | 200x200x200mm |
| Chamber insulation materials | lightweight aluminum oxide Ceramic fiber |
| Maximum Temp | 1200°c(Working time ≤ 3 hours) |
| Working Temp | 400-1700°c(justierbar, continuously Working) |
| Temperature controller way |
Based on the microprocessor 30 segments programmable and PID auto control |
| Heating Rate | 1-20°c/min (justierbar) |
| Temperature accuracy | ±1°c |
| Sensor of measuring Temp | B type thermocouple |
| Heating elements | nichrome Alloy resistance wire |
| Furnace shell structure | Double ventilation cooling structure |
| Cooling way | Fan cooling |
| Temperature display mode | Four Figure Liquid Crystal Display |
| Working power | AC 1-phase, 110-240 V 50/60Hz (User Choose any) |
| Rated power | 4.0KW |
| Packing Size(WxDXH) | 600x580x810mm |
| Spare function |
installed computer communication module and RS485 communication interface, to realize the remote control. (If need spare function, cost add By USD596.) |
Type |
Inside chamber size(W×H×D mm) |
Max temperature |
STA-1200X |
150×150×150mm |
1200°C |
STA-1200X |
150×150×200mm |
1200°C |
STA-1200X |
200×200×200mm |
1200°C |
STA-1200X |
200×200×300mm |
1200°C |
STA-1200X |
250×250×300mm |
1200°C |
STA-1200X |
300×300×400mm |
1200°C |
STA-1200X |
350×350×400mm |
1200°C |
STA-1200X |
400×400×400mm |
1200°C |
STA-1200X |
500×500×500mm |
1200°C |
STA universe group is founded in 2001,dedicating to innovation ang creating a world famous brand.And provide various products for customers. We are a professional manufacturer of it for many 13 years,our products are exported to America ,Russia,European,Germany,Brazil,India and many other countries.
