Tube Furnace Vacuun Tube Furnace
STA-1600-MT tube furnace is a CE certified compact furnace with 60 mm dia alumina processing tub & vacuum flangee, 30 segments programmable temperature controller at a working temperature up to 1600°C. It can be widely used for material and chemical lab to sinter all types of new materials samples under vacuum or other gas conditions.
Specification Furnace structure
- Double layer steel casing with air cooling.
- Two cooling fan inside to keep case temperature < 600C.
- High purity Alumina refractory chamber with max energy saving.
- Alumina tube, vacuum flange, gauge & valve are included
- Compact design ( click picture below to see dimension)
- Such compact space-saving furnace can be placed on the 600mm x 600mm mobile cart (available in the optional parts list below)
The Technical data of muffle furnace
Model |
STA-1600MT |
Tube Size |
2 3/8” X40” (60ODX54IDX1000mmL) |
Vacuum Sealing Kit |
60mm Vacuum Flange Assembly |
Furnace Structure |
1.Double layer steel casing with air cooling. 2.Two cooling fans inside to keep case temperature < 55oC. 3.1700 grade fiber alumina casted in vacuum
|
Power |
Max. 5KW |
Voltage |
Single Phase, 220V AC, 50/60 Hz |
Max. Working Temperature |
1600 oC (2912 oF) |
Normal Working Temperature |
800 -1550 oC (2822 oF) |
Max. Heating / Cooling Rate: |
5°C / min above 1200°C and 10°C/min below 1200°C |
Heating Zone |
455 mm |
Constant Temperature Zone |
150 mm (6") (+/- 1°C at 1600°C ) |
Heating Elements |
MoSi2 heating elements |
Temperature Controller |
|
Warranty |
One year limited manufacture warranty with life time support (consumable parts such as furnace liner, processing tubes, and O-rings are not covered by the warranty |
Compliance |
CE / ISO Certified |
| Model | Chamber size (Outer diameter of furnace tube x heating length) | Max. Temperature |
| STA-1600MT | Dia40x300mm (1.5"x12") | 1650.C |
| STA-1600MT | Dia40x450mm (1.5"x18") | 1650.C |
| STA-1600MT | Dia60x300mm (2.5"x12") | 1650.C |
| STA-1600MT | Dia60x450mm (2.5"x18") | 1650.C |
| STA-1600MT | Dia80x300mm (3.0"x12") | 1650.C |
| STA-1600MT | Dia80x450mm (3.0"x18") | 1650.C |
Warranty:Our products are warranted to be free from defects in materials or workmanship for one year from the date of purchase. Within this period, Across International will, at its sole options, replace any components that fail in normal use. Such replacement will be made at no charge to the customer for parts, provided that the customer shall be responsible for any transportation cost. This warranty does not cover consumables and failures due to abuse, misuse, accident or unauthorized alteration or repairs.
Replacement will be shipped to you after photo or other evidence are provided and investigated.
Standard Package
Description |
Flanges Set and sealing O-ring |
1000mm L alumina processing tube (O.D is selected by customer) |
B Type Thermal couple |
99.8% High purity Al2O3 Ceramic (made in US) |
Tube Blocks |
Furnace handle hook |
